RECIPROCATING COMPRESSORS
4
INTRODUCTION
Code numbers
(for ordering)
* Single pack: one compressor packed in a cardboard box
** Multi pack: a pallet filled with single-packs
*** Industrial pack: a full pallet of unpacked compressors
Packaging
The code numbers for NTZ compres-
sors are according to the standard
Danfoss numbering system. Below
tables list the code numbers for NTZ
compressors in single packs and
industrial packs.
At the publication date of this do-
cument NTZ compressors are only
available with motor voltage code 4.
For other motor voltage codes, please
check the availability.
NTZ compressors in single pack*
NTZ compressors in industrial pack**
Compressor
model
Code no.
Motor voltage code
1 3 4 5 6 7 9
Nominal voltage
208-
230/1/60
200-
230/3/60
460/3/60
400/3/50
230/1/50 230/3/50
575/3/60
500/3/50
380/3/60
NTZ048 120F0001
NTZ068 120F0002
NTZ096 120F0003
NTZ108 120F0004
NTZ136 120F0005
NTZ215 120F0006
NTZ271 120F0007
Compressor
model
Code no.
Motor voltage code
1 3 4 5 6 7 9
Nominal voltage
208-
230/1/60
200-
230/3/60
460/3/60
400/3/50
230/1/50 230/3/50
575/3/60
500/3/50
380/3/60
NTZ048 120F0008
NTZ068 120F0009
NTZ096 120F0010
NTZ108 120F0011
NTZ136 120F0012
NTZ215 120F0013
NTZ271 120F0014
Compressor
model
Single pack* Multi pack** Industrial pack***
Net weight
(kg)
Dimensions
(mm)
Qty
Net weight
(kg)
Dimensions
(mm)
Static
stacking
Qty
Net weight
(kg)
Dimensions
(mm)
Static
stacking
NTZ048 21
l: 330
w: 295
h: 385
6
142
l: 1000
w: 600
h: 510
4
12
279
l: 1200
w: 800
h: 500
4
NTZ068 23 151 295
NTZ096 35
l: 395
w: 365
h: 455
221
l: 1115
w: 800
h: 500
8
302
l: 1200
w: 800
h: 550
NTZ108 35 221 302
NTZ136 35 227 302
NTZ215 62
l: 485
w: 395
h: 600
396
l: 1200
w: 1000
h: 730
6
398
l: 1200
w: 800
h: 650
NTZ271 64 420 410
