RECIPROCATING COMPRESSORS
4 cylinders
99
158
232
202
246
205
246
115
ø 352
95
125
233
519
15
96
15°
15°
Threaded oil
sight glass
Schr
ader
1/4"
Mounting hole for PTC
crankcase heater
Suction rotolock
1"3/4
Discharge rotolock
1"1/4
Oil equalisation
3/8" (VE version only)
Rotolock connections size Pipe sizing Rotolock valve
Suction Discharge Suction Discharge Suction Discharge
NTZ215
NTZ271
1”3/4 1”1/4 1"1/8” 3/4” V02 V04
30
19
HM12-50
H M12-50
Silent block
8
OUTLINE DRAWINGS
