RECIPROCATING COMPRESSORS
68
25
98
68
109
82
Suction rotolock
1"1/4
Discharge rotolock
1"
333
PTC crankcase heater
Oil equalisation
3/8"
Schrader
1/4"
35
°
37
°
118
68
Suction 147
Discharge 142
39
123
159
Threaded oil
sight glass
141
263
17
17
°
ø 224
HM8-40
23
15
Silent block
6
1 cylinder
OUTLINE DRAWINGS
Rotolock connections size Pipe sizing Rotolock valve
Suction Discharge Suction Discharge Suction Discharge
NTZ048
NTZ068
1”1/4 1” 5/8” 1/2” V09 V06
