Danfoss MCX15B2 User Manual

© Danfoss | DCS (vt) | 2020.10
6 | AN320819413085en-000401
Connection
Connectors Type Dimensions
Top Board
Digital input 1 connector 3 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Digital output 14-15 connector 6 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Digital output 16-20 connector (MCX20B2) 10 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Analog input 11-14 connector (MCX20B2) 7 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Analog input 15-16 connector (MCX20B2) 4 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Digital input 2 connector 3 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Digital input 3 connector 3 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Digital input 4 connector 3 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Digital input 5-8 connector 5 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Digital input 9-13 connector 6 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Digital input 14-17 connector 5 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Digital input 18-22 connector 6 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Bottom Board
Digital output 1-5 connector 10 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Digital output 6-8 connector 6 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Ethernet connector 8 / 8 way RJ 45 plug type
USB host connector USB Type A
Analog input 1-6 connector 11 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Analog input 7-10 connector 6 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Power supply connector 2 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Digital output 9-13 connector 10 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
Analog output 1-6 connector 8 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
RS485 -2 connector 3 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
RS485-1connector 3 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
CAN connector 4 way screw plug-in connector type • pitch 5 mm
• section cable 0.2 – 2.5 mm²
CAN-RJ connector 6/6 way telephone RJ12 plug type
USB DEV connector USB Mini B
