Danfoss PTU 025 Programming Guide

13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[76] Digital Input x30 2
[77] Digital Input x30 3
[78] Digital Input x30 4
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive Mode
[91] ECB Bypass Mode
[92] ECB Test Mode
[100] Fire Mode
See 13-15 RS-FF Operand S, 13-16 RS-
FF Operand R.
13-43 Logic Rule Operator 2
Array [6]
Option: Function:
Select the second logical operator to be used
on the boolean input calculated in
•
Parameter 13-40 Logic Rule Boolean 1
•
Parameter 13-41 Logic Rule Operator 1
•
Parameter 13-42 Logic Rule Boolean 2
13-43 Logic Rule Operator 2
Array [6]
Option: Function:
and the boolean input coming from
parameter 13-42 Logic Rule Boolean 2.
[13-44] signies the boolean input of
parameter 13-44 Logic Rule Boolean 3.
[13-40/13-42] signies the boolean input
calculated in
•
Parameter 13-40 Logic Rule Boolean 1
•
Parameter 13-41 Logic Rule Operator 1
•
Parameter 13-42 Logic Rule Boolean 2
[0] DISABLED
Select this option to ignore
parameter 13-44 Logic Rule Boolean 3
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND
NOT
[8] NOT OR NOT
13-44 Logic Rule Boolean 3
Array [6]
Option: Function:
Select the third boolean (TRUE or
FALSE) input for the selected logic
rule.
See parameter 13-40 Logic Rule
Boolean 1 for further descriptions of
options and their functions.
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
Parameter Descriptions
VLT
®
HVAC Drive FC 102
114 Danfoss A/S © 03/2015 All rights reserved. MG11CE02
