Danfoss PTU 025 Programming Guide

0-30 Custom Readout Unit
Option: Function:
[171] lb/in²
[172] in WG
[173] ft WG
[174] in Hg
[180] HP
0-31 Custom Readout Min Value
Range: Function:
Size
related*
[ -999999.99 -
100.00
CustomRea-
doutUnit]
This parameter allows selection of
the minimum. value of the custom-
dened readout (occurs at zero
speed). It is only possible to select a
value dierent to 0 when selecting a
linear unit in parameter 0-30 Custom
Readout Unit. For quadratic and cubic
units the minimum value is 0.
0-32 Custom Readout Max Value
Range: Function:
100 Custom-
ReadoutUnit*
[ par. 0-31 -
999999.99
CustomRea-
doutUnit]
This parameter sets the max.
value to be shown when the
speed of the motor has reached
the set value for
parameter 4-13 Motor Speed High
Limit [RPM] or
parameter 4-14 Motor Speed High
Limit [Hz] (depends on setting in
parameter 0-02 Motor Speed
Unit).
0-37 Display Text 1
Range: Function:
0* [0 -
25 ]
In this parameter, it is possible to write an individual
text string for display in the LCP or to be read via
serial communication. If to be displayed permanently,
select [37] Display Text 1 in
•
Parameter 0-20 Display Line 1.1 Small
•
0-21 Display Line 1.2 Small
•
0-22 Display Line 1.3 Small
•
0-23 Display Line 2 Large
•
0-24 Display Line 3 Large
•
Parameter 0-37 Display Text 1
is linked to 12-08 Host Name. Changing 12-08 Host
Name changes Parameter 0-37 Display Text 1 - but not
vice versa.
0-38 Display Text 2
Range: Function:
0* [0 -
25 ]
In this parameter, it is possible to write an individual
text string for display in the LCP, or to be read via
serial communication. If to be displayed permanently,
select [38] Display Text 2 in:
•
Parameter 0-20 Display Line 1.1 Small
•
0-21 Display Line 1.2 Small
•
0-22 Display Line 1.3 Small
•
0-23 Display Line 2 Large
•
0-24 Display Line 3 Large
Press [
▲
] or [
▼
] to change a character. Press [
◀
] and
[
▶
] to move the cursor. When a character is
highlighted by the cursor, this character can be
changed. A character can be inserted by placing the
cursor between 2 characters and pressing [
▲
] or [
▼
].
0-39 Display Text 3
Range: Function:
0* [0 -
25 ]
In this parameter it is possible to write an individual
text string for display in the LCP or to be read via
serial communication. If to be displayed permanently
select Display Text 3 in parameter 0-20 Display Line
1.1 Small, 0-21 Display Line 1.2 Small, 0-22 Display
Line 1.3 Small, 0-23 Display Line 2 Large or
0-24 Display Line 3 Large. Press [
▲
] or [
▼
] to change
a character. Press [
◀
] and [
▶
] to move the cursor.
When a character is highlighted by the cursor, this
character can be changed. A character can be
inserted by placing the cursor between 2 characters
and pressing [
▲
] or [
▼
].
3.2.5
0-4* LCP Keypad
Enable, disable and password protect individual keys on
the LCP.
0-40 [Hand on] Key on LCP
Option: Function:
[0] Disabled Avoid accidental usage of the key.
[1] * Enabled [Hand On] key enabled.
[2] Password
Avoid unauthorised start in Hand mode. If
parameter 0-40 [Hand on] Key on LCP is included
in My Personal Menu, dene the password in
parameter 0-65 Personal Menu Password.
Otherwise, dene the password in
parameter 0-60 Main Menu Password.
Parameter Descriptions Programming Guide
MG11CE02 Danfoss A/S © 03/2015 All rights reserved. 33
