Danfoss PVED-CLS Startup Guide

P3097 input voltage scaling
Input voltage 12V coil 24V coil
12V 100% N/A
24V 50% 100%
36V 33% 67%
PVED-CLS parameter acceptance
Use the following steps to save and approve the parameters that have been set.
1. Press Download and wait for the script to complete.
2. Click Close.
It is mandatory to confirm that the parameters have been downloaded by the user.
3. Press Approve Parameters.
The text will change to Approved and the page can then be closed.
Leaving the page before parameters are accepted will cause an EEPROM fault and the PVED-CLS will
go to safe-state mode.
Application Guide
PVED-CLS startup guide
Parameter setting
8 |
©
Danfoss | October 2018 AB285975085591en-000101
