FRCC.ES.011.A1.02
13
MANUAL TECHNICAL DATA OVERVIEW
Transmission frequencies 2.402 GHz to 2.480 GHz
Range Max. 10 m
Bluetooth® Interface
Supported Bluetooth® pro les
Generic Access Pro le
Serial Port Pro le
Transmission power (Class 2) max. 4dBm
Serial interface Connector
RS485 with male DSUB-9 plug con-
nector
USB interface
Mini USB port 2.0 for charging and
power supply
Battery
Type
Lithium-Ion rechargeable battery,
3.7V/540mAh
Operating time
Maximum 10 hours (115.2 kBit/s),
fully charged
Charging time Maximum 2 h
DC interface
DC power jack 0.65 mm, 6 - 24 V DC
stabilized
LED1 Status display for battery
LED2 Status display for gateway
Casing
ABS translucent blue, dimensions
80x40x18 mm
Standard con guration
Baud rate 19200 Bit/s
Stop bit 1
Parity Even
Data bits 8
Bluetooth® PIN 1234
Weight including antenna and battery 62 grams
Operating temperature -20 to +60°C
Charging temperature 0 to +45 °C
Storage temperature -20 to +45°C
