14
FRCC.ES.011.A1.02
MANUAL GATE WAY STATUS
The Secop Bluetooth® gateway operates as a gateway between a controller and a computer.
LED2 (Status) indicates the operating status of the gateway.
LED2 Sequence Meaning
LED ashes green for approx. 3 seconds in
short, rapid bursts
...............
RS485 Bluetooth® gateway begins Slave mode
operation
LED ashes green in slow, short bursts
. . . . . . . .
RS485 Bluetooth® gateway is in normal operating
mode
– RS485 COM-HARDWA RE service is active.
Incoming connections are accepted.
LED alternates rapidly between red and green
...............
RS485 Bluetooth® gateway is in normal operating
mode
– RS485 COM-HARDWA RE service is active.
A connection between PC and gateway has been
successfully established (Tool4Cool® is running).
LED ashes green for approx. 3 seconds in
short, rapid bursts followed by slow short
bursts
..... . . . . .
RS485 Bluetooth® gateway is in manual operation
mode
– RS485 COM-HARDWA RE service is not active.
(Tool4Cool® is not running) or wrong communica-
tion setup (e.g.
pairing).
LED ashes red for approx. 3 seconds in short,
rapid bursts
...............
RS485 Bluetooth® gateway is defective.
Solution: Please return for service.
