Neutral Adjustment (EDC) (bottom view)
Solenoid shaft
Feedback pin
Adjusting
screw
(cam)
P106 046E
Maximum
adjustment
less than 120°
Control spool
Illustration shows how cam on adjusting pin rotates to adjust for neutral position after pump is re-
installed.
Service Manual
Series 40 M46 Variable Pumps
Adjustments
©
Danfoss | September 2017 11026743 | AX00000027en-US0202 | 27
