Danfoss Series 40 M46 Service Manual

Fastener size and torque chart
Item Fastener Wrench size Torque
920 Servo piston cover screws 3/8 hex 15 N•m [11 lbf•ft]
921 Servo piston cover screws 3/8 hex 15 N•m [11 lbf•ft]
130 Front cover screw T50 Torx 58 N•m [43 lbf•ft]
163 Front cover screws T55 Torx 91 N•m [67 lbf•ft]
1506 Rear cover screws 9/16 hex 77 N•m [57 lbf•ft]
806 Filtration cover screw 1/2 hex 30 N•m [22 lbf•ft]
115 Lock/seal nut 11/16 hex 37 N•m [27 lbf•ft]
927 Displacement limiter lock/seal nut 9/16 hex 19 N•m [14 lbf•ft]
1213 Control handle nut 1/2 hex 15 N•m [11 lbf•ft]
1210 Screw 3/8 14 N•m [10 lbf•ft]
Plug size and torque chart
Item O-ring plug Wrench size Torque
102 3/4 16 UNF 1 inch hex 108 N•m [80 lbf•ft]
107 1-1/16 12 UNF 9/16 internal hex 115 N•m [85 lbf•ft
110 9/16 18 UNF 11/16 hex 37 N•m [27 lbf•ft]
111 9/16 18 UNF 11/16 hex 37 N•m [27 lbf•ft]
158 7/16 20 UNF 9/16 hex 20 N•m [15 lbf•ft]
810 9/16 18 UNF 11/16 hex 37 N•m [27 lbf•ft]
1001 5/8 18 UNF 5/8 hex 20 N•m [15 lbf•ft]
1101 1-5/16 12 UNF 1-1/4 hex 176 N•m [130 lbf•ft]
1102 1-5/16 12 UNF 1-1/4 hex 176 N•m [130 lbf•ft]
Service Manual
Series 40 M46 Variable Pumps
Torque chart
