VLT
®
5000/6000/8000 Series
According to international
requir
ements
VLT typ
e
6350 6450 6500 6550
8350 8450 8500 8550
Rated input
current
I
L,N
[A] (400 V) 467 584 648 734
I
L, N
(460 V) 431 526 581 668
2 x 150 2 x 185 2 x 240 2 x 300
Max. cross-section of copper cable to power
(380-415 V) [mm
2
]
5)
3x70 3x95 3x120 3x150
2 x 120 2 x 150 2 x 185 2 x 300
Max. cross-section of copper cable to power
(440-460 V) [mm
2
]
5)
3 x 70 3 x 95 3 x 95 3 x 120
2 x 185 2 x 240 2 x 300
Max. cross-section of aluminium cable to
power (380-415 V) [mm
2
]
5)
3 x 120 3 x 150 3 x 185 3 x 185
2 x 150 2 x 185 2 x 240
Max. cross-section of aluminium cable to
power (440-460 V) [mm
2
]
5)
3 x 95 3 x 120 3 x 150 3 x 185
2x250mcm 2x350mcm 2x400mcm 2x500mcm
Max. cross-section of copper cable to power
(380-415 V) AWG]
2) 5)
3 x 2/0 3 x3/0 3 x 4/0 3x250mcm
2 x 4/0 2x300mcm 2x350mcm 2x500mcm
Max. cross-section of copper cable to power
(440-460 V) AWG]
2) 5)
3 x 1/0 3 x 3/0 3 x 3/0 3 x 4/0
2x350mcm 2x500mcm 2x600mcm 2x700mcm
Max. cross-section of aluminium cable to
power (380-415 V) AWG]
2) 5)
3 x 4/0 3x250mcm 3x300mcm 3x350mcm
2x300mcm 2x400mcm 2x500mcm 2x600mcm
Max. cross-section of aluminium cable to
power (440-460 V) AWG]
2) 5)
3 x 3/0 3 x 4/0 3x250mcm 3x300mcm
Max. pre-fuses (mains)[-]/UL
1)
[A] 630/600 700/700 800/800 800/800
Integral pre-fuses (softcharge circuit)[-]/UL
6)
[A] 9/9 9/9 9/9 9/9
Integral p
re-fuses (snubber resistors)[-]/UL
7)
[A]
15/15 15/15 15/15 15/15
Integral pre-fuses (SMPS) 5.0/5.0
Efficiency 0.97
Weight IP 00 kg (lb)
480
(1058)
515
(1135)
560
(1235)
585
(1290)
Weight Nema 1 (IP 20) kg (lb)
595
(1132)
630
(1389)
675
(1488)
700
(1543)
Weight IP 54 kg (lb)
605
(1334)
640
(1411)
685
(1510)
710
(1565)
Power loss a
tmax. load[W]
7500 9450 10650 12000
Enclosure IP 00 / Nema 1 (IP 20) / IP 54
1. For t
ype of fuse see section Fuses.
2. American Wire Gauge.
3. Measured using 30 m screened motor cables
at ra
tedloadandratedfrequency.
4. Min. cable cross-section is the smallest cable
cross-section allowed to be fitted on the terminals.
Alwa
ys comply with national and local regulations
on min. cable cross-section.
5. Connection stud 2 x M12/3 x M12.
6. If UL
/cUL is to be complied with, AC
Littelfuse type KLK, Danfoss ordering no.
175L3489 must be used.
7. If UL
/cUL is to be complied with, DC
Littelfuse type KLKD, Danfoss ordering no.
176F1147 must be used.
8. If UL
/cUL is to be complied with, Bussmann type
KTK-5, Danfoss ordering no. 175L3437
must be used.
MG.56.A2.02 - VLT is a registered Danfoss trademark
10
