Danfoss VLT 6000 series Manual

VLT
®
5000/6000/8000 Series
Introduction
■
Mains supply 3 x 380-500 V
Accord
ing to international
requirements VLT type 6350 6450 6500 6550
8350 8450 8500 8550
Output
current
I
VLT,N
[A] (380-415 V)
480 600 658 745
I
VLT, MAX
(60 s)[A](380-415 V) 528 660 724 820
I
VLT,N
[A] (440-460 V) 443 540 590 678
I
VLT, MAX
(60 s)[A](440-460 V) 487 594 649 746
Output S
VLT,N
[kVA] (380-415 V) 333 416 456 516
S
VLT,N
[
kVA] (440-460 V)
384 468 511 587
Typical shaft output (380-415 V) P
VLT,N
[kW] 250 315 355 400
Typical shaft output (380-415 V) P
VLT,N
[HP] 300 350 450 500
Typical shaft output (440-460 V) P
VLT,N
[kW] 315 355 400 500
Typical shaft output (440-460 V) P
VLT,N
[HP] 350 450 500 600
Max. cross-section of copper cable to motor, 2 x 150 2 x 185 2 x 240 2 x 300
brake and
loadsharing (380-415 V) [mm
2
]
5)
3x70 3x95 3x120 3x150
Max. cross-section of copper cable to motor 2 x 120 2 x 150 2 x 185 2 x 300
and loadsharing (440-460 V) [mm
2
]
5)
3 x 70 3 x 95 3 x 95 3 x 120
2 x 185 2 x 240 2 x 300
Max. cross-section of aluminium cable to
motor and loadsharing (380-415 V) [mm
2
]
5)
3 x 120 3 x 150 3 x 185 3 x 185
2 x 150 2 x 185 2 x 240
Max. cross-section of aluminium cable to
motor and loadsharing (440-460) [mm
2
]
5)
3 x 95 3 x 120 3 x 150 3 x 185
2x250mcm 2x350mcm 2x400mcm 2x500mcm
Max. cross-section of copper cable to motor
and loadsharing (380-415 V) AWG]
2) 5)
3 x 2/0 3 x3/0 3 x 4/0 3x250mcm
2 x 4/0 2x300mcm 2x350mcm 2x500mcm
Max. cross-section of copper cable to motor
and loadsharing (440-460 V) AWG]
2) 5)
3 x 1/0 3 x 3/0 3 x 3/0 3 x 4/0
2x350mcm 2x500mcm 2x600mcm 2x700mcm
Max. cross-section of aluminium cable to
motor and loadsharing (380-415 V) AWG]
2) 5)
3 x 4/0 3x250mcm 3x300mcm 3x350mcm
2x300mcm 2x400mcm 2x500mcm 2x600mcm
Max. cross-section of aluminium cable to
motor and loadsharing (440-460 V) AWG]
2) 5)
3 x 3/0 3 x 4/0 3x250mcm 3x300mcm
1. For type of fuse see section Fuses.
2. American Wire Gauge.
3. Measured using 30 m screened motor cables
atratedloadandratedfrequency.
4. Min. cable cross-section is the smallest cable
cross-section allowed to be fitted on the terminals.
Always comply with national and local regulations
on min. cable cross-section.
5. Connection stud 2 x M12/3 x M12.
6. If UL/cUL is to be complied with, AC
Littelfuse type KLK, Danfoss ordering no.
175L3489 must be used.
7. If UL/cUL is to be complied with, DC
Littelfuse type KLKD, Danfoss ordering no.
176F1147 must be used.
8. If UL/cUL is to be complied with, Bussmann type
KTK-5, Danfoss ordering no. 175L3437
must be used.
MG.56.A2.02 - VLT is a registered Danfoss trademark
9
