Danfoss VLT 6000 series Manual

VLT
®
5000/6000/8000 Series
■
Compact, Mains supply 3 x 380 - 500 V
According to international requirements VLT type 5300 5350 5450 5500
Rated input current
110%
I
L,MAX
[A] (400 V) 467 584 648 734
I
L,MAX
[A] (460 V)
431 526 581 668
Rated input current
150%
I
L,MAX
[A] (400 V) 389 467 584 648
I
L,MAX
[A] (460 V) 356 431 526 581
Max. cross-section of copper cable 2x150 2x185 2x240 2x300
to power (380-440 V) [mm
2
]
5)
3x70 3x95 3x120 3x150
Max. cross-section of copper cable 2x120 2x150 2x185 2x300
to power (441-500 V) [mm
2
]
5)
3x70 3x95 3x95 3x120
Max. cross-section of aluminium cable 2x185 2x240 2x300
to power (380-440 V) [mm
2
]
5)
3x120 3x150 3x185 3x185
Max. cross-section of aluminium cable 2x150 2x185 2x240
to power (441-500 V) [mm
2
]
5)
3x95 3x120 3x150 3x185
Max. cross-section of copper cable 2x250mcm 2x350mcm 2x400mcm 2x500mcm
to power (380-440 V) [AWG]
2) 5)
3x2/0 3x3/0 3x4/0 3x250mcm
Max. cross-section of copper cable 2x4/0 2x300mcm 2x350mcm 2x500mcm
to power (441-500 V) [AWG]
2) 5)
31/0 3x3/0 3x3/0 3x4/0
Max. cross-section of aluminium cable 2x350mcm 2x500mcm 2x600mcm 2x700mcm
to power (380-440 V) [AWG]
2) 5)
3x4/0 3x250mcm 3x300mcm 3x350mcm
Max. cross-section of aluminium cable 2x300mcm 2x400mcm 2x500mcm 2x600mcm
to power (441-500 V) [AWG]
2) 5)
3x3/0 3x4/0 3x250mcm 3x300mcm
Max. pre-fuses (mains) [-]/UL
1)
[A] 630/600 700/700 800/800 800/800
Integral pre-fuses (softcharge circuit)
[-]/UL
6)
[A]
9/9 9/9 9/9 9/9
Integral pre-fuses (snubber resistors)
[-]/UL
7)
[A]
15/15 15/15 15/15 15/15
Integral
pre-fuses (SMPS) [-]/UL
8)
[A]
5.0/5.0 5.0/5.0 5.0/5.0 5.0/5.0
Efficiency 0.97 0.97 0.97 0.97
Weight IP
00
kg (lb) 480 (1058
)
515 (1135
)
560 (1235
)
585 (1290
)
Weight Nema 1 kg (lb) 595 (1132) 630 (1389) 675 (1488) 700 (1543)
Weight IP 5
4
kg (lb) 605 (1334) 640 (1411) 685 (1510) 710 (1565)
Power loss at max. load [W] 7500 9450 10650 12000
Enclosure IP 00 / Nema
1 (IP 20) / IP 54
1. For type of fuse see section Fuses.
2. American Wire Gauge.
3. Measure
d using 30 m screened motor cables at rated load and rated frequency.
4. Min. cable cross-section is the smallest cable cross-section allowed to be fitted on the terminals. Always
comply with national and local regulations on min. cable cross-section.
5. Connect
ion stud 2 x M12/3 x M12.
6. If UL/cUL is to be complied with, AC Littelfuse type KLK, Danfoss ordering no. 175L3489 must be used.
7. If UL/cUL is to be complied with, DC Littelfuse type KLKD, Danfoss ordering no. 176F1147 must be
used.
8. If UL/cUL is to be complied with, Bussmann type KTK-5, Danfoss ordering no. 175L3437 must be used.
MG.56.A2.02 - VLT is a registered Danfoss trademark
