VLT
®
8000 AQUA
Programming
509 - 532 Data read-out
Value:
Parame-
ter no.
Description Display text Unit Updating
interval
509 Resulting reference (REFERENCE %) % 80 msec.
510 Resulting reference [unit] (REFERENCE [UNIT]) Hz, rpm 80 msec.
511 Feedback [unit] (FEEDBACK) Par. 415 80 msec.
512 Frequency [Hz] (FREQUENCY) Hz 80 msec.
513 User-defined read-out (CUSTOM READOUT) Hz x scaling 80 msec.
514 Motor current [A] (CURRENT) Amp 80 msec.
515 Power [kW] (POWER KW) kW 80 msec.
516 Motor voltage [V] (POWER HK) HP 80 msec.
517 Motor voltage [V] (MOTOR VOLT) V
AC
80 msec.
518 DC link voltage [V] (DC LINK VOLTAGE) V
DC
80 msec.
519 Thermal load, motor [%] (MOTOR TEMPERATURE) % 80 msec.
520 Thermal load, VLT [%] (VLT TEMPERATURE) % 80 msec.
521 Digital input (DIGITAL INPUT) Binary 80 msec.
522 Terminal 53, analog input [V] (TERMINAL 53, ANALOG
INPUT)
Volt 20 msec.
523 Terminal 54, analog input [V] (TERMINAL 54, ANALOG
INPUT)
Volt 20 msec.
524 Terminal 60, analog input [mA] (TERMINAL 60, ANALOG
INPUT)
mA 20 msec.
525 Pulse reference [Hz] (PULSE REFERENCE) Hz 20 msec.
526 External reference [%] (EXTERNAL REFERENCE) % 20 msec.
527 Status word (STATUS WORD HEX) Hex 20 msec.
528 Heat sink temperature [°C] (HEAT SINK TEMP.) °C 1.2 sec.
529 Alarm word (ALARM WORD, HEX) Hex 20 msec.
530 Control word (VLT CONTROL WORD, HEX) Hex 2 msec.
531 Warning word (WARN. WORD) Hex 20 msec.
532 Extended status word (STATUS WORD) Hex 20 msec.
537 Relay status (RELAY STATUS) Binary 80 msec.
Function:
These parameters can be read out via the serial
communication port and via the display. See also
parameters 007-010 Display read-out.
Description of choice:
Resulting reference, parameter 509:
gives a percentage for the resulting reference in the
range from Minimum reference, Ref
MIN
to Maximum
reference, Ref
MAX
.SeealsoReference handling.
Resulting reference [unit], parameter 510:
gives the resulting reference by means of the
unit Hz in Open loop (parameter 100). In Closed
loop, the reference unit is selected in parameter
415 Units with closed loop.
Feedback [unit], parameter 511:
gives the resulting feedback value by means of the
unit/scaling selected in parameters 413, 414 and
415. See also Feedback handling.
Frequency [Hz], parameter 512:
gives the output frequency from the frequency converter.
User-defined read-out, parameter 513:
gives a user-defined value calculated on the basis
of the present output frequency and unit, as well as
the scaling in selected in parameter 005 Max. value
of user-defined read-out. The unit is selected in
parameter 006 Unit for user-defined read-out.
Motor current [A], parameter 514:
Gives the motor phase current measured
as an effective value.
Power [kW], parameter 515:
Gives the present power absorption of the motor in kW.
Power [HP], parameter 516:
Gives the present power absorption of the motor in HP.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.83.A2.02 - VLT is a registered Danfoss trademark
163
