VLT
®
8000 AQUA
Motor voltage, parameter 517:
Gives the voltage fed to the motor.
DC link voltage, parameter 518:
Gives the intermediate circuit voltage of the
frequency converter.
Thermal load, motor [%], parameter 519:
Gives the calculated/estimated thermal load on
the motor. 100 % is the cut-out limit. See also
parameter 117 Motor thermal protection.
Thermal protection, VLT [%], parameter 520:
Gives the calculated/estimated thermal load on the
frequency converter. 100 % is the cut-out limit.
Digital input, parameter 521:
Gives the signal status of the 8 inputs (16, 17,
18, 19, 27, 29, 32 and 33). Input 16 corresponds
to the bit to the extreme left.
’0’ = no signal, ’1’ = signal connected.
Terminal 53, analog input [V], parameter 522:
Gives the voltage value of the signal on terminal 53.
Terminal 54, analog input [V], parameter 523:
Gives the voltage value of the signal on terminal 54.
Terminal erminal 60, analog input [mA],
parameter 524:
Gives the current value of the signal on terminal 60.
Pulse reference [Hz], parameter 525:
Gives a pulse frequency in Hz connected to one
of the terminals 17 and 29.
External reference, parameter 526:
Gives the sum of external references as a percentage
(sum of analog/pulse/serial communication) in
the range from Minimum reference, Ref
MIN
to
Maximum reference, Ref
MAX
.
Status word, parameter 527:
Gives the present status word of the frequency
converter in Hex.
Heat sink temperature, parameter 528:
Gives the present heat sink temperature of the
frequency converter. The cut-out limit is 90 ± 5 °C/41
F, while cutting back in is effected at 60 ± 5 °C/41 F.
Alarm word, parameter 529:
Gives a Hex code for the alarm on the frequency
converter. See Warning words 1+2 and Alarm word.
Control word, parameter 530:
Gives the present control word of the frequency
converter in Hex.
Warning word, parameter 531:
Indicates in Hex whether there is a warning on
the frequency converter. See Warning words
1+2 and Alarm word.
Extended status word, parameter 532:
Indicates in Hex code whether there is a warning
on the frequency converter. See Warning
words 1+2 and Alarm word.
Relay status, parameter 537:
Indicates in binary code whether the output relays of
the frequency converter are triggered or not.
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
MG.83.A2.02 - VLT is a registered Danfoss trademark
164
