Danfoss VLT 8000 AQUA series User Manual

VLT
®
8000 AQUA
All about VLT 8000
AQUA
■ Factory settings
PNU
#
Parameter
description
Factory setting Range Changes
during
operation
4-setup Conver-
sion
index
Data
type
300 Terminal 16 Digital input Reset Yes Yes 0 5
301 Terminal 17 Digital input No operation Yes Yes 0 5
302 Terminal 18 Digital input Start Yes Yes 0 5
303 Terminal 19 Digital input Reversing Yes Yes 0 5
304 Terminal 27 Digital input Safety interlock/
Coasting stop,
inverse
Yes Yes 0 5
305 Terminal 29 Digital input Jog Yes Yes 0 5
306 Terminal 32 Digital input No operation Yes Yes 0 5
307 Terminal 33 Digital input No operation Yes Yes 0 5
308 Terminal 53, analog input voltage No operation Yes Yes 0 5
309 Terminal 53, min. scaling 0.0 V 0.0 - 10.0 V Yes Yes -1 5
310 Terminal 53, max. scaling 10.0 V 0.0 - 10.0 V Yes Yes -1 5
311 Terminal 54, analog input voltage No operation Yes Yes 0 5
312 Terminal 54, min. scaling 0.0 V 0.0 - 10.0 V Yes Yes -1 5
313 Terminal 54, max. scaling 10.0 V 0.0 - 10.0 V Yes Yes -1 5
314 Terminal 60, analog input voltage Reference Yes Yes 0 5
315 Terminal 60, min. scaling 4.0 mA 0.0 - 20.0 mA Yes Yes -4 5
316 Terminal 60, max. scaling 20.0 mA 0.0 - 20.0 mA Yes Yes -4 5
317 Time out 10 sec. 1 - 99 sec. Yes Yes 0 5
318 Function after time out Off Yes Yes 0 5
319 Terminal 42, output 0-I
MAX
⇒4-20 mA Yes Yes 0 5
320 Terminal 42, output
pulse scaling Yes Yes 0 6
321 Terminal 42, output 0-f
MAX
⇒0-20 mA Yes Yes 0 5
322 Terminal 45, output, Yes Yes
pulse scaling 5000 Hz 1 - 32000 Hz Yes Yes 0 6
323 Relay 1, output function No alarm Yes Yes 0 5
324 Relay 01, ON delay 0.00 sec. 0 - 600 sec. Yes Yes 0 6
325 Relay 01, OFF delay 2.00 sec. 0 - 600 sec. Yes Yes 0 6
326 Relay 2, output function Running Yes Yes 0 5
327 Pulse reference,
max frequency
5000 Hz Depends on
input terminal
Yes Yes 0 6
328 Pulse feedback, max. frequency 25000 Hz 0 - 65000 Hz Yes Yes 0 6
364 Terminal 42, bus control 0 0.0 - 100 % Yes Yes -1 6
365 Terminal 45, bus control 0 0.0 - 100 % Yes Yes -1 6
) Coasting stop, inverse is global factory setting different from North American factory setting.
Changes during operation:
"Yes" means that the parameter can be changed,
while the frequency converter is in operation. "No"
means that the frequency converter must be stopped
before a change can be made.
4
-Setup:
"Yes" means that the parameter can be programmed
individually in each of the four setups, i.e. the
same para-meter can have four different data
values. "No" means that the data value will be
the same in all four setups.
C
onversion index:
This number refers to a conversion figure to be
used when writing or reading to or from a frequency
converter by means of serial communicatio
n.
Conversion index Conversion factor
74 0.1
2 100
110
01
-1 0.1
-2 0.01
-3 0.001
-4 0.0001
Data type:
Data type shows the type and length of the
telegram.
Data type Description
3 Integer 16
4 Integer 32
5 Unsigned 8
6Unsigned16
7Unsigned32
9Textstring
MG.83.A2.02 - VLT is a registered Danfoss trademark
199
