■ Factory settings
PNU
#
Parameter
description
Factory setting Range Changes
during
operation
4-setup Conver-
sion
index
Data
type
400 Reset function Infinate Automatic Yes Yes 0 5
401 Automatic restart time 10 sec. 0 - 1800 sec. Yes Yes 0 6
402 Flying start Enable Yes Yes -1 5
403 Sleep mode timer Off 0 - 300 sec. Yes Yes 0 6
404 Sleep frequency 0Hz f
MIN
- Par. 405 Yes Yes -1 6
405 Wake up frequency 60 Hz/ 50 Hz Par. 404 - f
MAX
Yes Yes -1 6
406 Boost setpoint 100% 1 - 200 % Yes Yes 0 6
407 Switching frequency Depends on the
unit
1.5 - 14.0 kHz Yes Yes 2 5
408 Interference reduction
method
ASFM Yes Yes 0 5
409 Function in case of no
load
Warning Yes Yes 0 5
410 Function at mains failure Trip Yes Yes 0 5
411 Function at overtempera-
ture
Trip Yes Yes 0 5
412 Trip delay overcurr ent,
I
LIM
60 sec 0 - 60 sec. Yes Yes 0 5
413 Minimum feedback, FB
MIN
0.000 -999,999.999 -
FB
MIN
Yes Yes -3 4
414 Maximum feedback,
FB
MAX
100.000 FB
MIN
- 999,999.999 Yes Yes -3 4
415 Units relating to closed
loop
%YesYes-15
416 Feedback conversion Linear Yes Yes 0 5
417 Feedback calculation Maximum Yes Yes 0 5
418 Setpoint 1 0.000 FB
MIN
-FB
MAX
Yes Yes -3 4
419 Setpoint 2 0.000 FB
MIN
-FB
MAX
Yes Yes -3 4
420 PID normal/inverse
control
Normal Yes Yes 0 5
421 PID anti windup On Yes Yes 0 5
422 PID start-up frequency 0Hz f
MIN
-f
MAX
Yes Yes -1 6
423 PID proportional gain 0.01 0.00 - 10.00 Yes Yes -2 6
424 PID start-up frequency Off 0.01 - 9999.00
s. (Off)
Yes Yes -2 7
425 PID differentiation time Off 0.0 (Off) - 10.00 sec. Yes Yes -2 6
426 PID differentiator gain
limit
5.0 5.0 - 50.0 Yes Yes -1 6
427 PID lowpass filter time 0.01 0.01 - 10.00 Yes Yes -2 6
433 Motor alternation time 0(OFF) 0-999hrs Yes Yes 0 6
434 Motor alteration function Ramp Ramp/Coast Yes Yes 0 6
463 Enhanced sleep mode
timer
0 0-9999 Yes Yes 0 6
464 Wakeup pressure 0Ref
MIN
-Setpoint1 Yes Yes -3 4
465 Pump min freq 20 f
MIN
-f
MAX
Yes Yes -1 6
466 Pump max freq 50 f
MIN
-f
MAX
Yes Yes -1 6
467 NF power at min freq 0 0-16000 W Yes Yes 0 7
468 NF power at max freq 0 0-16000 W Yes Yes 0 7
469 No/low flow power
compensation
1.2 0.01-9.99 Yes Yes -2 6
470 Dry run timeout 30 sec. 5-30 sec. Yes Yes 0 5
471 Dry run interlock timer 30 min. 0.5-60 min. Yes Yes -1 6
483 Dynamic DC link
compensation
On No No 0 5
) Global factory setting different from North
American factory setting
MG.83.A2.02 - VLT is a registered Danfoss trademark
