Danfoss VLT 8000 AQUA series User Manual

VLT
®
8000 AQUA
All about VLT 8000
AQUA
■ Factory settings
PNU
#
Parameter
description
Factory setting Range Changes
during
opera-
tion
4-setup Con-
ver-
sion
index
Data
type
500 Protocol FC Yes Yes 0 5
501 Address 001 Depends on
par.500
Yes No 0 5
502 Baudrate 9600 BAUD Yes No 0 5
503 Coasting LOGIC OR Yes Yes 0 5
504 DC-brake LOGIC OR Yes Yes 0 5
506 Start LOGIC OR Yes Yes 0 5
506 Reversing DIGITAL INPUT Yes Yes 0 5
507 Selection of Setup LOGIC OR Yes Yes 0 5
508 Selection of Preset Reference LOGIC OR Yes Yes 0 5
509 Data Read-out: Reference % No No -1 3
510 Data Read-out: Reference Unit No No -3 4
511 Data Read-out: Feedback No No -3 4
512 Data Read-out: Frequency No No -1 6
513 User Defined Read-out No No -2 7
514 Data Read-out: Current No No -2 7
515 Data Read-out: Power, kW No No 1 7
516 Data Read-out: Power, HP No No -2 7
517 Data Read-out: Motor Voltage No No -1 6
518 Data Read-out: DC Link Voltage No No 0 6
519 Data Read-out: Motor temp. No No 0 5
520 Data Read-out: VLT Temp. No No 0 5
521 Data Read-out: Digital Input No No 0 5
522 Data Read-out: Terminal 53, Analog Input No No -1 3
523 Data Read-out: Terminal 54, Analog Input No No -1 3
524 Data Read-out: Terminal 60 Analog Input No No -4 3
525 Data Read-out: Pulse reference No No -1 7
526 Data Read-out: External Reference % No No -1 3
527 Data Read-out: Status Word, Hex No No 0 6
528 Data Read-out: Heat Sink Temperatur No No 0 5
529 Data Read-out: Alarm Word, Hex No No 0 7
530 Data Read-out: Control Word, Hex No No 0 6
531 Data Read-out: Warning Word, Hex No No 0 7
532 Data Read-out: Extended Status Word, Hex No No 0 7
533 Display Text 1 No No 0 9
534 Display Text 2 No No 0 9
535 Bus Feedback 1 00000 No No 0 3
536 Bus Feedback 2 00000 No No 0 3
537 Data Read-out: Relay Status No No 0 5
555 BusTimeInterval 60 sec. 1 to 99 sec. Yes Yes 0 5
556 Bus Time Interval Function NO FUNCTION Yes Yes 0 5
570 Modbus parity and message framing No parity 1 stopbit Yes Yes 0 5
571 Modbus communications timeout 100 ms 10-2000 ms Yes Yes -3 6
