Danfoss VLT AHF 005 Programming Guide

15-14 Samples Before Trigger
Range: Function:
50* [0 -
100 ]
Enter the percentage of all samples before a
trigger events which is to be retained in the log.
See also parameter 15-12 Trigger Event and
parameter 15-13 Logging Mode.
3.15.3 15-2* Historic Log
View up to 50 logged data items via the array parameters
in this parameter group. For all parameters in the group,
[0] is the most recent data, and [49] is the oldest data.
Data is logged every time an event occurs (not to be
confused with SLC events). Events in this context are
dened as a change in 1 of the following areas:
•
Digital input.
•
Digital outputs.
•
Warning word.
•
Alarm word.
•
Status word.
•
Control word.
•
Extended status word.
Events are logged with value and time stamp in ms. The
time interval between 2 events depends on how often
events occur (maximum once every scan time). Data
logging is continuous, but if an alarm occurs, the log is
saved and the values can be viewed on the display. This
feature is useful, for example when carrying out service
following a trip. View the historic log contained in this
parameter via the serial communication port or via the
display.
15-20 Historic Log: Event
Array [50]
Range: Function:
0* [0 - 255 ] View the event type of the logged events.
15-21 Historic Log: Value
Array [50]
Range: Function:
0* [0 -
2147483647 ]
View the value of the logged event.
Interpret the event values according to this
table:
Digital input
Decimal value. See
parameter 16-60 Digital
Input for description after
converting to binary
value.
15-21 Historic Log: Value
Array [50]
Range: Function:
Digital output
(not
monitored in
this SW
release)
Decimal value. See
16-66 Digital Output [bin]
for a description after
converting to binary
value.
Warning word Decimal value. See
16-92 Warning Word for a
description.
Alarm word Decimal value. See
16-90 Alarm Word for a
description.
Status word
Decimal value. See
parameter 16-03 Status
Word for a description
after converting to binary
value.
Control word
Decimal value. See
parameter 16-00 Control
Word for a description.
Extended
status word
Decimal value. See
16-94 Ext. Status Word for
a description.
15-22 Historic Log: Time
Array [50]
Range: Function:
0 ms* [0 - 2147483647
ms]
View the time at which the logged
event occurred. Time is measured in
ms since frequency converter start. The
maximum value corresponds to
approximately 24 days, which means
that the count restarts at zero after
this time period.
15-23 Historic log: Date and Time
Array [50]
Range: Function:
Size related* [ 0 - 0 ] Array parameter; Date & Time 0–49: This
parameter shows at which time the
logged event occurred.
3.15.4 15-3* Alarm Log
Parameters in this group are array parameters, where up to
10 fault logs can be viewed. [0] is the most recent logged
data, and [9] is the oldest. Fault codes, values, and time
stamp can be viewed for all logged data.
Parameter Descriptions
VLT
®
HVAC Drive FC 102
126 Danfoss A/S © 03/2015 All rights reserved. MG11CE02
