16-77 Analog Out X30/8 [mA] 0 N/A All set-ups FALSE -3 Int16
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1 0 N/A All set-ups FALSE 0 V2
16-82 Fieldbus REF 1 0 N/A All set-ups FALSE 0 N2
16-84 Comm. Option STW 0 N/A All set-ups FALSE 0 V2
16-85 FC Port CTW 1 0 N/A All set-ups FALSE 0 V2
16-86 FC Port REF 1 0 N/A All set-ups FALSE 0 N2
16-9* Diagnosis Readouts
16-90 Alarm Word 0 N/A All set-ups FALSE 0 Uint32
16-91 Alarm Word 2 0 N/A All set-ups FALSE 0 Uint32
16-92 Warning Word 0 N/A All set-ups FALSE 0 Uint32
16-93 Warning Word 2 0 N/A All set-ups FALSE 0 Uint32
16-94 Ext. Status Word 0 N/A All set-ups FALSE 0 Uint32
16-95 Ext. Status Word 2 0 N/A All set-ups FALSE 0 Uint32
16-96 Maintenance Word 0 N/A All set-ups FALSE 0 Uint32
5.1.17 18-** Info & Rèadouts
Param
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
18-0* Maintenance Log
18-00 Maintenance Log: Item 0 N/A All set-ups FALSE 0 Uint8
18-01 Maintenance Log: Action 0 N/A All set-ups FALSE 0 Uint8
18-02 Maintenance Log: Time 0 s All set-ups FALSE 0 Uint32
18-03 Maintenance Log: Date and Time ExpressionLimit All set-ups FALSE 0 TimeOfDay
18-1* Fire Mode Log
18-10 FireMode Log:Event 0 N/A All set-ups FALSE 0 Uint8
18-11 Fire Mode Log: Time 0 s All set-ups FALSE 0 Uint32
18-12 Fire Mode Log: Date and Time ExpressionLimit All set-ups FALSE 0 TimeOfDay
18-3* Inputs & Outputs
18-30 Analog Input X42/1 0 N/A All set-ups FALSE -3 Int32
18-31 Analog Input X42/3 0 N/A All set-ups FALSE -3 Int32
18-32 Analog Input X42/5 0 N/A All set-ups FALSE -3 Int32
18-33 Analog Out X42/7 [V] 0 N/A All set-ups FALSE -3 Int16
18-34 Analog Out X42/9 [V] 0 N/A All set-ups FALSE -3 Int16
18-35 Analog Out X42/11 [V] 0 N/A All set-ups FALSE -3 Int16
18-36 Analog Input X48/2 [mA] 0 N/A All set-ups TRUE -3 Int32
18-37 Temp. Input X48/4 0 N/A All set-ups TRUE 0 Int16
18-38 Temp. Input X48/7 0 N/A All set-ups TRUE 0 Int16
18-39 Temp. Input X48/10 0 N/A All set-ups TRUE 0 Int16
18-5* Ref. & Feedb.
18-50 Sensorless Readout [unit] 0 SensorlessUnit All set-ups FALSE -3 Int32
5.1.18 20-** FC Closed Loop
Param
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
20-0* Feedback
20-00 Feedback 1 Source [2] Analog Input 54 All set-ups TRUE - Uint8
20-01 Feedback 1 Conversion [0] Linear All set-ups FALSE - Uint8
20-02 Feedback 1 Source Unit ExpressionLimit All set-ups TRUE - Uint8
20-03 Feedback 2 Source [0] No function All set-ups TRUE - Uint8
20-04 Feedback 2 Conversion [0] Linear All set-ups FALSE - Uint8
Parameter Lists Programming Guide
MG11CE02 Danfoss A/S © 03/2015 All rights reserved. 237
5 5
