Danfoss VLT AHF 005 Instruction Manual

Size/type Bussmann PN* Littelfuse Rating
P315, 380–480 V KTK-4 4 A, 600 V
P450-P500, 525–690 V KTK-4 4 A, 600 V
P355-P1M0, 380–480 V KLK-15 15 A, 600 V
P560-P1M4, 525–690 V KLK-15 15 A, 600 V
Table 4.19 Fan Fuses
Size/type [A]
Bussmann
PN*
Rating [V] Alternative fuses
P500-P1M0,
380–480 V
2.5–4.0 LPJ-6 SP
or SPI
6 A, 600 Any listed Class J Dual Element, Time Delay, 6 A
P710-P1M4,
525–690 V
LPJ-10 SP
or SPI
10 A, 600 Any listed Class J Dual Element, Time Delay, 10 A
P500-P1M0,
380–480 V
4.0–6.3 LPJ-10 SP
or SPI
10 A, 600 Any listed Class J Dual Element, Time Delay, 10 A
P710-P1M4,
525–690 V
LPJ-15 SP
or SPI
15 A, 600 Any listed Class J Dual Element, Time Delay, 15 A
P500-P1M0,
380–480 V
6.3–10 LPJ-15 SP
or SPI
15 A, 600 Any listed Class J Dual Element, Time Delay, 15 A
P710-P1M4,
525–690 V
LPJ-20 SP
or SPI
20 A, 600 Any listed Class J Dual Element, Time Delay, 20 A
P500-P1M0,
380–480 V
10–16 LPJ-25 SP
or SPI
25 A, 600 Any listed Class J Dual Element, Time Delay, 25 A
P710-P1M4,
525–690 V
LPJ-20 SP
or SPI
20 A, 600 Any listed Class J Dual Element, Time Delay, 20 A
Table 4.20 Manual Motor Controller Fuses
Enclosure size Bussmann PN* Rating Alternative fuses
F LPJ-30 SP or SPI 30 A, 600 V Any listed Class J Dual Element,
Time Delay, 30 A
Table 4.21 30 A Fuse-protected Terminal Fuse
Enclosure size Bussmann PN* Rating Alternative fuses
F LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Element,
Time Delay, 6 A
Table 4.22 Control Transformer Fuse
Enclosure size Bussmann PN* Rating
F GMC-800MA 800 mA, 250 V
Table 4.23 NAMUR Fuse
Enclosure size Bussmann PN* Rating Alternative fuses
F LP-CC-6 6 A, 600 V Any listed Class CC, 6 A
Table 4.24 Safety Relay Coil Fuse with PILZ Relay
Electrical Installation
Instruction Manual
MG11F522 Danfoss A/S © 08/2014 All rights reserved. 53
