5-40 Function Relay
Option: Function:
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[84] SL digital output E
[85] SL digital output F
[155] Verifying Flow
[160] No alarm
[161] Running reverse
[164] Local ref active, not OFF
[165] Local ref active
[166] Remote ref active
[167] Start command activ
[168] Hand mode
[169] Auto mode
[180] Clock Fault
[181] Prev. Maintenance
[183] Pre/Post Lube
[188] AHF Capacitor Connect
[189] External Fan Control
[190] No-Flow
[191] Dry Pump
[192] End Of Curve
[193] Sleep Mode
[194] Broken Belt
[195] Bypass Valve Control
[198] Drive Bypass
[199] Pipe Filling
[211] Cascade Pump 1
[212] Cascade Pump 2
[213] Cascade Pump 3
[214] Cascade Pump 4
[215] Cascade Pump 5
[216] Cascade Pump 6
[217] Cascade Pump 7
[218] Cascade Pump 8
[219] Cascade Pump 9
[230] Ext. Cascade Ctrl
5-53 Term. 29 High Ref./Feedb. Value
Range: Function:
100 * [-999999.999 -
999999.999 ]
Enter the high reference value
[RPM] for the motor shaft speed
and the high feedback value, see
also 5-58 Term. 33 High Ref./Feedb.
Value.
5.2.7 6-** Analog In/Out
Parameter group for configuration of the analog input and
output.
6-00 Live Zero Timeout Time
Range: Function:
10 s* [1 -
99 s]
Enter the Live Zero Time-out time period. Live
Zero Time-out Time is active for analog inputs, i.e.
terminal 53 or terminal 54, used as reference or
feedback sources. If the reference signal value
associated with the selected current input falls
below 50% of the value set in
parameter 6-10 Terminal 53 Low Voltage,
6-12 Terminal 53 Low Current,
parameter 6-20 Terminal 54 Low Voltage or
6-22 Terminal 54 Low Current for a time period
longer than the time set in parameter 6-00 Live
Zero Timeout Time, the function selected in
parameter 6-01 Live Zero Timeout Function is
activated.
How to programme the freque... VLT AQUA Drive FC 202 Operation Instructions
98 MG20P402 - Rev. 2013-12-16
55
