Danfoss VLT AQUA FC 202 User Manual

23-01 ON Action
Arra [10]
Option: Function:
[37] Set digital out F low
[38] Set digital out A high
[39] Set digital out B high
[40] Set digital out C high
[41] Set digital out D high
[42] Set digital out E high
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
[74] Start Timer 7
[80] Sleep Mode
[81] Derag
NOTICE
For choices [32] - [43], see also parameter group 5-3*
Digital Outputs and 5-4* Relays.
23-02 OFF Time
Array [10]
Range: Function:
Size related* [ 0 - 0 ] Sets the OFF time for the Timed Action.
NOTICE
The frequency converter has no
back up of the clock function and
the set date/time will reset to
default (2000-01-01 00:00) after a
power down unless a Real Time
Clock module with back up is
installed. In 0-79 Clock Fault it is
possible to program for a Warning
in case clock has not been set
properly, e.g. after a power down.
23-03 OFF Action
Array [10]
Option: Function:
Select the action during OFF Time.
See 13-52 SL Controller Action for
descriptions of the options.
[0] Disabled
[1] No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
23-03 OFF Action
Array [10]
Option: Function:
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
[15] Select preset ref 5
[16] Select preset ref 6
[17] Select preset ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] DC Brake
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out A low
[33] Set digital out B low
[34] Set digital out C low
[35] Set digital out D low
[36] Set digital out E low
[37] Set digital out F low
[38] Set digital out A high
[39] Set digital out B high
[40] Set digital out C high
[41] Set digital out D high
[42] Set digital out E high
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
[74] Start Timer 7
[80] Sleep Mode
[81] Derag
How to programme the freque... VLT AQUA Drive FC 202 Operation Instructions
110 MG20P402 - Rev. 2013-12-16
