Danfoss VLT AQUA FC 202 User Manual

23-04 Occurrence
Array [10]
Option: Function:
Select which day(s) the Timed Action
applies to. Specify working/non-working
days in 0-81 Working Days, 0-82 Additional
Working Days and 0-83 Additional Non-
Working Days.
[0] All days
[1] Working days
[2] Non-working days
[3] Monday
[4] Tuesday
[5] Wednesday
[6] Thursday
[7] Friday
[8] Saturday
[9] Sunday
5.2.11 29-** Water Application
FunctionsWater Application
Functions
The group contains parameters used for monitoring water/
wastewater applications.
29-00 Pipe Fill Enable
Option: Function:
[0] Disabled Select Enabled to fill pipes at a user specified rate.
[1] Enabled Select Enabled to fill pipes with a user specified
rate.
29-01 Pipe Fill Speed [RPM]
Range: Function:
Size
related*
[ par.
4-11 -
par. 4-13
RPM]
Set the filling speed for filling horizontal
pipe systems. The speed can be selected
in Hz or RPM depending on the choices
made in parameter 4-11 Motor Speed Low
Limit [RPM]/parameter 4-13 Motor Speed
High Limit [RPM] or in 4-12 Motor Speed
Low Limit [Hz]/4-14 Motor Speed High Limit
[Hz].
29-02 Pipe Fill Speed [Hz]
Range: Function:
Size
related*
[ par.
4-12 -
par. 4-14
Hz]
Set the filling speed for filling horizontal
pipe systems. The speed can be selected
in Hz or RPM depending on the choices
made in parameter 4-11 Motor Speed Low
Limit [RPM]/parameter 4-13 Motor Speed
High Limit [RPM] or in 4-12 Motor Speed
Low Limit [Hz]/4-14 Motor Speed High Limit
[Hz].
29-03 Pipe Fill Time
Range: Function:
0 s* [0 - 3600 s] Set the specified time for pipe filling of
horizontal pipe systems.
29-04 Pipe Fill Rate
Range: Function:
0.001
ProcessCtrlUnit*
[0.001 -
999999.999
ProcessCtrlUnit]
Specifies the filling rate in
units/second using the PI
controller. Filling rate units
are feedback units/second.
This function is used for
filling-up vertical pipe
systems but will be active
when the filling-time has
expired, no matter what ,
until the pipe fill-set-point
set in 29-05 Filled Setpoint
is reached.
29-05 Filled Setpoint
Range: Function:
0
ProcessCtrlUnit*
[-999999.999 -
999999.999
ProcessCtrlUnit]
Specifies the Filled Set-
point at which the Pipe
Fill Function will be
disabled and the PID
controller will take control.
This function can be used
both for horizontal and
vertical pipe systems.
How to programme the freque... VLT AQUA Drive FC 202 Operation Instructions
MG20P402 - Rev. 2013-12-16 111
5 5
