0-22 Display Line 1.3 Small
Option: Function:
Select a variable for display in line 1,
right position.
[1614] * Motor
Current
The options are the same as those listed
for 0-20 Display Line 1.1 Small.
0-23 Display Line 2 Large
Option: Function:
Select a variable for display in line 2.
[1615] * Frequency The options are the same as those listed for
par. 0-20 Display Line 1.1 Small
0-24 Display Line 3 Large
Option: Function:
[1652] * Feedback [Unit] The options are the same as those
listed for 0-20 Display Line 1.1 Small.
Select a variable for display in line 2.
0-37 Display Text 1
Range: Function:
0 * [0 -
25 ]
In this parameter it is possible to write an
individual text string for display in the LCP or to be
read via serial communication. If to be displayed
permanently select Display Text 1 in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
or 0-24 Display Line 3 Large. Press [
▲
] or [
▼
] to
change a character. Press [
◀
] and [
▶
] to move the
cursor. When a character is highlighted, it can be
changed. Press [
▲
] or [
▼
] to change a character. A
character can be inserted by placing the cursor
between 2 characters and pressing [
▲
] or [
▼
].
0-38 Display Text 2
Range: Function:
0 * [0 -
25 ]
In this parameter it is possible to write an
individual text string for display in the LCP or to be
read via serial communication. If to be displayed
permanently select Display Text 2 in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
or 0-24 Display Line 3 Large. Press [
▲
] or [
▼
] to
change a character. Press [
◀
] and [
▶
] to move the
cursor. When a character is highlighted by the
cursor, this character can be changed. A character
can be inserted by placing the cursor between two
characters and pressing [
▲
] or [
▼
].
0-39 Display Text 3
Range: Function:
0 * [0 -
25 ]
In this parameter it is possible to write an
individual text string for display in the LCP or to be
read via serial communication. If to be displayed
permanently select Display Text 3 in 0-20 Display
0-39 Display Text 3
Range: Function:
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
or 0-24 Display Line 3 Large. Press [
▲
] or [
▼
] to
change a character. Press [
◀
] and [
▶
] to move the
cursor. When a character is highlighted by the
cursor, this character can be changed. A character
can be inserted by placing the cursor between 2
characters and pressing [
▲
] or [
▼
].
0-70 Date and Time
Range: Function:
Size
related*
[ 0 - 0 ] Sets the date and time of the internal
clock. The format to be used is set in
0-71 Date Format and parameter 0-72 Time
Format.
0-71 Date Format
Option: Function:
[0] YYYY-MM-DD Sets the date format to be used in the LCP.
[1] DD-MM-YYYY Sets the date format to be used in the LCP.
[2] MM/DD/YYYY Sets the date format to be used in the LCP.
0-72 Time Format
Option: Function:
Sets the time format to be used in the LCP.
[0] 24 h
[1] 12 h
0-74 DST/Summertime
Option: Function:
Choose how Daylight Saving Time/Summertime
should be handled. For manual DST/Summertime
enter the start date and end date in
parameter 0-76 DST/Summertime Start and
parameter 0-77 DST/Summertime End.
[0] Off
[2] Manual
0-76 DST/Summertime Start
Range: Function:
Size related* [ 0 - 0 ] Sets the date and time when
summertime/DST starts. The date is
programmed in the format selected in
0-71 Date Format.
0-77 DST/Summertime End
Range: Function:
Size related* [ 0 - 0 ] Sets the date and time when
summertime/DST ends. The date is
programmed in the format selected in
0-71 Date Format.
