Options [120] - [138] are related to the Cascade Controller
functionality. For more information, see parameter group
25-** Cascade Controller.
Digital input function Option Terminal
No operation [0] All *term 32, 33, 29, 19
Reset [1] All
Coast inverse [2] All * term 27
Coast and reset inverse [3] All
DC-brake inverse [5] All
Stop inverse [6] All
External interlock [7] All
Start [8] All
Latched start [9] All
Reversing [10] All
Start reversing [11] All
Jog [14] All
Preset reference on [15] All
Preset ref bit 0 [16] All
Preset ref bit 1 [17] All
Preset ref bit 2 [18] All
Freeze reference [19] All
Freeze output [20] All
Speed up [21] All
Speed down [22] All
Set-up select bit 0 [23] All
Set-up select bit 1 [24] All
Pulse input [32] term 29, 33
Ramp bit 0 [34] All
Mains failure inverse [36] All
Ref source bit 0 [42] All
Hand/Auto Start [51] All
Run Permissive [52] All
Hand start [53] All
Auto start [54] All
DigiPot Increase [55] All
DigiPot Decrease [56] All
DigiPot Clear [57] All
Counter A (up) [60] 29, 33
Counter A (down) [61] 29, 33
Reset Counter A [62] All
Counter B (up) [63] 29, 33
Counter B (down) [64] 29, 33
Reset Counter B [65] All
Sleep Mode [66] All
Reset Maintenance Word [78] All
PTC Card 1 [80] All
Latched Pump Derag [85] All
Lead Pump Start [120] All
Lead Pump Alternation [121] All
Pump 1 Interlock [130] All
Pump 2 Interlock [131] All
Pump 3 Interlock [132] All
Table 5.7 Functions for Digital Inputs
All = Terminals 18, 19, 27, 29, 32, X30/2, X30/3, X30/4. X30/
are the terminals on MCB 101.
How to programme the freque...
VLT AQUA Drive FC 202 Operation Instructions
MG20P402 - Rev. 2013-12-16 93
