Danfoss VLT AutomationDrive FC 300 Series Service Guide

Block Diagram Name
Spare Part Number
Spare Part Name Comments 200–240 V AC
D1h/D3h D2h/D4h
FC 102 (T2) N55K N75K N90K N100 N150 N160 FC 202 (T2) N55K N75K N90K N100 N150 N160 FC 302 (T2) N45K N55K N75K N90K N100 N150
Control Cards PCA1 130B1151 Control Card, FC 102 coated, no safe stop 102 102 102 102 102 102
PCA1 134B1730 Control Card, FC 102 coated, no safe stop, Ver 2 card 102 102 102 102 102 102
PCA1 130B1150 Control Card, FC 102 coated, safe stop 102 102 102 102 102 102
PCA1 134B1729 Control Card, FC 102 coated, safe stop, Ver 2 card 102 102 102 102 102 102
PCA1 130B6968 Control Card, FC 103 coated, no safe stop 103 103 103 103 103 103
PCA1 134B1724 Control Card, FC 103 coated, no safe stop, Ver 2 card 103 103 103 103 103 103
PCA1 130B6967 Control Card, FC 103 coated, safe stop 103 103 103 103 103 103
PCA1 134B1714 Control Card, FC 103 coated, safe stop, Ver 2 card 103 103 103 103 103 103
PCA1 130B1168 Control Card, FC 202 coated, no safe stop 202 202 202 202 202 202
PCA1 134B1732 Control Card, FC 202 coated, no safe stop, Ver 2 card 202 202 202 202 202 202
PCA1 130B1167 Control Card, FC 202 coated, safe stop 202 202 202 202 202 202
PCA1 134B1731 Control Card, FC 202 coated, safe stop, Ver 2 card 202 202 202 202 202 202
PCA1 130B1128 Control Card, FC 301 coated, no safe stop 301 301 301 301 301 301
PCA1 134B1728 Control Card, FC 301 coated, no safe stop, Ver 2 card 301 301 301 301 301 301
PCA1 130B1126 Control Card, FC 301 coated, safe stop 301 301 301 301 301 301
PCA1 134B1727 Control Card, FC 301 coated, safe stop, Ver 2 card 301 301 301 301 301 301
PCA1 130B1109 Control Card, FC 302 coated, safe stop 302 302 302 302 302 302
PCA1 134B1726 Control Card, FC 302 coated, safe stop, Ver 2 card 302 302 302 302 302 302
Power Cards PCA2 176F3832 Power Card NO 55kW 200–240V Power card, conformal coated, does not incl scaling card T2 – – – – –
PCA2 176F3834 Power Card NO 75kW 200–240V Power card, conformal coated, does not incl scaling card – T2 – – – –
PCA2 176F3835 Power Card NO 90kW 200–240V Power card, conformal coated, does not incl scaling card – – T2 – – –
PCA2 176F3836 Power Card NO 110kW 200–240V Power card, conformal coated, does not incl scaling card – – – T2 – –
PCA2 176F3837 Power Card NO 150kW 200–240V Power card, conformal coated, does not incl scaling card – – – – T2 –
PCA2 176F3838 Power Card NO 160kW 200–240V Power card, conformal coated, does not incl scaling card – – – – – T2
Other Printed Circuit Cards
PCA3 176F3154 Current scaling card 3.82 OHM 400V Installs on the power card 1 – – – – –
PCA3 176F3155 Current scaling card 3.11 OHM 400V Installs on the power card – 1 – – – – PCA3 176F3156 Current scaling card 2.56 OHM 400V Installs on the power card – – 1 – – –
PCA3 176F3156 Current scaling card 2.56 OHM 400V Installs on the power card – – – 1 – –
PCA3 176F3157 Current scaling card 5.10 OHM 400V Installs on the power card – – – – 1 –
Spare Parts
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
326 Danfoss A/S © 02/2019 All rights reserved. MG94A502
