Block

Diagram

Name

Spare

Part

Number

Spare Part Name Comments 200–240 V AC

D1h/D3h D2h/D4h

FC 102 (T2) N55K N75K N90K N100 N150 N160

FC 202 (T2) N55K N75K N90K N100 N150 N160

FC 302 (T2) N45K N55K N75K N90K N100 N150

PCA3 176F3158 Current scaling card 4.22 OHM 400V Installs on the power card – – – – – 1

PCA4 176F3833 Inrush card NO 55-160KW 200V Soft-charge / inrush card 1 1 1 1 1 1

PCA5 176F3160 Gate drive card NO 110-315KW 400V Gate drive card 1 1 1 1 1 1

PCA6 176F3387 RFI card NO 110-315kW 400V RFI class A1 board 1 1 1 1 1 1

PCA7 176F3161 Balance/HF card NO 110-315KW 400V DC Bus Cap Balance / High Freq card 1 1 1 1 1 1

Semiconductors

SCR 1,2,3 176F3337 Rectier SCR/diode 503A 1600V 1 SCR/Diode per kit - See product note 185 – – – – 3 3

SCR 1,2,3 176F8318 Rectier SCR/diode 175A 1600V 1 SCR/Diode per kit 3 3 3 – – –

SCR 1,2,3 176F8320 Rectier SCR/diode 330A 1600V 1 SCR/Diode per kit. Incl 1 stando to inrush bd-177G4369 – – – 3 3 –

IGBT 1,2,3 176F3362 IGBT dual module 300A 1200V 1 IGBT pet kit 3 – – – – –

IGBT 1,2,3 176F3363 IGBT dual module 450A 1200V 1 IGBT pet kit – 3 3 – – –

IGBT 1,2,3 176F3364 IGBT dual module 600A 1200V 1 IGBT pet kit – – – 3 – –

IGBT 1,2,3 176F3365 IGBT dual module 900A 1200V 1 IGBT pet kit – – – – 3 3

IGBT 4 176F3366 IGBT brake module 450A 1700V 1 IGBT pet kit brake brake brake – – –

IGBT 4 176F3367 IGBT brake module 650A 1700V 1 IGBT pet kit – – – brake brake brake

Capacitors

CBANK 1 176F3163 DC bus cap 4700UF 450V in housing DC Bus Cap, 450VDC, w black cup, 1 per kit 4 6 6 8 10 12

C1, C2, C3 176F8323 IGBT snubber cap 1000V 1.5UF snubber cap 3 3 3 – – –

C4 176F8534 IGBT snubber cap 1250V 1.0UF snubber cap, brake IGBT 1 1 1 – – –

C1, C2, C3 176F3162 IGBT snubber cap 1000V 1.5UF wide mount snubber cap – – – 3 3 3

C4 176F3427 IGBT snubber cap 1250V 1.0UF wide mount snubber cap, brake IGBT – – – 1 1 1

Fans

F2 176F3164 Heatsink Fan DC 172x51 - 48VDC Heatsink Fan 1 1 1 1 1 1

F1 176F3166 Top fan IP20 DC 80X25 - 48VDC IP20 Top Fan, Fan only, 1 per kit IP20 IP20 IP20 – – –

F1 176F3167 Top fan IP20 DC 80X38 - 48VDC IP20 Top Fan, Fan only, 1 per kit – – – IP20 IP20 IP20

F1 176F3168 Door fan IP21/54 DC 120X25 IP21/IP54 Door Fan, Fan Only, 1 fan per kit 21/54 21/54 21/54 – – –

F1 176F3169 Door fan IP21/54 DC 120X38 IP21/IP54 Door Fan, Fan Only, 1 fan per kit – – – 21/54 21/54 21/54

F3 176F3165 Mixing fan DC 40X28 - 24VDC Mixing Fan, mounted below the input terminals 1 1 1 1 1 1

Fuses

FU 1,2,3 176F3170 Fuse 315A 700V square body Mains fuses, 1 per kit 3 – – – – –

FU 1,2,3 176F3171 Fuse 350A 700V square body Mains fuses, 1 per kit – 3 – – – –

FU 1,2,3 176F3172 Fuse 400A 700V square body Mains fuses, 1 per kit – – 3 – – –

Spare Parts Service Guide

15 15
