Block

Diagram

Name

Spare

Part

Number

Spare part name Comments 525–690 V AC (T7)

D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h

FC 102 N75k N90k N110 N132 N160 N200 N250 N315 N400

FC 103 N75k N90k N110 N132 N160 N200 N250 N315 N400

FC 202 N75k N90k N110 N132 N160 N200 N250 N315 N400

FC 302 N55k N75k N90k N110 N132 N160 N200 N250 N315

176F3480 Power terminal cover IP20 D4h enclosure Enclosure – – – – – IP20 IP20 IP20 IP20

176F3481 Mains shield D1h enclosure Enclosure 21/54 21/54 21/54 21/54 21/54 – – – –

176F3482 Mains shield D2h enclosure Enclosure – – – – – 21/54 21/54 21/54 21/54

176F8430 Cable clamp for enclosure size D & E Enclosure – – – – – 4 4 4 4

130B0264 Cradle for A5,B1,B2,C1 and C2 enclosure Insulation – – – – – 1 1 1 1

176F3344 Bracket gatedrive support D2h/D4h Insulation – – – – – 1 1 1 1

176F3348 Bracket inrush support D1h/D3h Insulation 1 1 1 1 1 – – – –

176F3349 Bracket gatedrive support D1h/D3h Insulation 1 1 1 1 1 – – – –

176F3354 Insulation mains terminals D1h/D3h Insulation 1 1 1 1 1 – – – –

176F3355 Insulation motor terminals D1h/D3h Insulation 1 1 1 1 1 – – – –

176F3361 Bracket inrush support D2h/D4h w/ 2 standos Insulation – – – – – 1 1 1 1

176F3369 Mains terminals D2h/D4h Insulation – – – – – 1 1 1 1

176F3370 Motor terminals D2h/D4h Insulation – – – – – 1 1 1 1

176F3388 Cradle for LCP D1h/D3h enclosure Insulation 1 1 1 1 1 – – – –

176F3540 Heat Sink fan cover Dxh enclosures Enclosure 1 1 1 1 1 1 1 1 1

176F3548 Cover DC link coil large Dxh enclosure Enclosure – – – – – 1 1 1 1

176F3549 Cover DC link coil small Dxh enclosure Enclosure 1 1 1 1 1 – – – –

176F5000 Anti condensation heater Dxh enclosure Resistor 1 1 1 1 1 1 1 1 1

176F5734 Front cover IP21/IP54 D1h enclosure Enclosure 21/54 21/54 21/54 21/54 21/54 – – – –

176F5735 Front cover IP21/IP54 D2h enclosure Enclosure – – – – – 21/54 21/54 21/54 21/54

176F5736 Front cover no LCP IP21/54 D1h enclosure Enclosure 21/54 21/54 21/54 21/54 21/54 – – – –

176F5737 Front cover no LCP IP21/54 D2h enclosure Enclosure – – – – – 21/54 21/54 21/54 21/54

176F5739 Extended option adaptor plate D1h enclosure Enclosure 1 1 1 1 1 – – – –

176F5740 Extended option adaptor plate D2h enclosure Enclosure – – – – – 1 1 1 1

176F5741 Gland plate D1h enclosure Enclosure 21/54 21/54 21/54 21/54 21/54 – – – –

176F5742 Gland plate D2h enclosure Enclosure – – – – – 21/54 21/54 21/54 21/54

176F5748 Top plate assembly D4h Enclosure – – – – – IP20 IP20 IP20 IP20

176F5747 Enclosure left side D4h Enclosure – – – – – IP20 IP20 IP20 IP20

176F5749 Enclosure right side D4h Enclosure – – – – – IP20 IP20 IP20 IP20

176F6304 Front cover D2 w/ disconnect short cab. Enclosure – – – – – 21/54 21/54 21/54 21/54

176F6313 Top terminal cover D3h inverter only Enclosure – – – 1 1 – – – –

Spare Parts

VLT

FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9

1515
