Danfoss VLT AutomationDrive FC 300 Series Service Guide

Block Diagram Name
Spare Part Number
Spare part name Comments 525–690 V AC (T7)
D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h
FC 102 N75k N90k N110 N132 N160 N200 N250 N315 N400 FC 103 N75k N90k N110 N132 N160 N200 N250 N315 N400
FC 202 N75k N90k N110 N132 N160 N200 N250 N315 N400
FC 302 N55k N75k N90k N110 N132 N160 N200 N250 N315
176F3358 Busbar mains, fuse, no RFI D1h/D3h Busbars 1 1 1 1 1 – – – –
176F3359 Busbar mains, RFI, no fuse D1h/D3h Busbars 1 1 1 1 1 – – – –
176F3360 Busbar mains, fuse, RFI D1h/D3h Busbars 1 1 1 1 1 – – – – 176F3368 Busbar motor terminals U,V,W D2h/D4h Busbars – – – – – 1 1 1 1 176F3371 Busbar mains, no fuse, no RFI D2h/D4h Busbars – – – – – 1 1 1 1
176F3372 Busbar mains, fuse, no RFI D2h/D4h Busbars – – – – – 1 1 1 1
176F3373 Busbar mains, RFI, no fuse D2h/D4h Busbars – – – – – 1 1 1 1
176F3374 Busbar mains, fuse, RFI D2h/D4h Busbars – – – – – 1 1 1 1
176F3376 Busbar SCR AC input small D2h/D4h Busbars – – – – – 3 3 – –
176F3377 Busbar SCR AC input large D2h/D4h Busbars – – – – – – – 3 3 176F3378 Busbar SCR DC output small D2h/D4h Busbars – – – – – 2 2 – –
176F3379 Busbar SCR DC output large D2h/D4h Busbars – – – – – – – 2 2
176F3380 Busbar DC+ SCR to DC coil D2h/D4h Busbars – – – – – 1 1 1 1 176F3381 Busbar DC- SCR to DC coil D2h/D4h Busbars – – – – – 1 1 1 1
176F3382 Busbar DC+ inductor to cap bank D2h/D4h Busbars – – – – – 1 1 1 1
176F3383 Busbar DC- inductor to cap bank D2h/D4h Busbars – – – – – 1 1 1 1 176F3384 Busbar IGBT AC output D2h/D4h Busbars – – – – – 3 3 3 3 176F3385 Busbar assy current sensor D2h/D4h Busbars – – – – – 1 1 1 1 176F3430 Busbar assy cap bank 690V D1h/D3h Busbars 1 1 1 1 1 – – – –
176F3432 Busbar assy cap bank 690V D2h/D4h Busbars – – – – – 1 1 1 1
Other Parts 176F3353 Door fan lter Dxh enclosure, pkg of 10 Fan lter 21/54 21/54 21/54 21/54 21/54 21/54 21/54 21/54 21/54
176F3342 Air bae D2h enclosure Enclosure – – – – – 21/54 21/54 21/54 21/54 176F3343 Air bae D4h enclosure Enclosure – – – – – IP20 IP20 IP20 IP20 176F3345 Cable clamp 45mm Dxh enclosure Enclosure 4 4 4 4 4 – – – – 176F3351 Air bae D3h enclosure Enclosure IP20 IP20 IP20 IP20 IP20 – – – – 176F3352 Air bae D1h enclosure Enclosure 21/54 21/54 21/54 21/54 21/54 – – – –
176F3375 Door vent kit IP21/IP54 Dxh enclosure Enclosure 21/54 21/54 21/54 21/54 21/54 21/54 21/54 21/54 21/54 176F3389 Front cover IP20 D4h enclosure Enclosure – – – – – IP20 IP20 IP20 IP20 176F3390 Front cover IP20 D3h enclosure Enclosure IP20 IP20 IP20 IP20 IP20 – – – –
176F3479 Power terminal cover IP20 D3h enclosure Enclosure IP20 IP20 IP20 IP20 IP20 – – – –
