Block
Diagram
Name
Spare
Part
Number
Spare part name Comments 525–690 V AC (T7)
D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h
FC 102 N75k N90k N110 N132 N160 N200 N250 N315 N400
FC 103 N75k N90k N110 N132 N160 N200 N250 N315 N400
FC 202 N75k N90k N110 N132 N160 N200 N250 N315 N400
FC 302 N55k N75k N90k N110 N132 N160 N200 N250 N315
CBL2 176F3319 Cable control card to power card D2h/D4h Ribbon cable, control card to power card – – – – – 1 1 1 1
CBL3 176F3320 Cable power card to door fan D1h/D3h Wire harness, PCA to H/S fan & door/top fan 1 1 1 1 1 – – – –
CBL3 176F3321 Cable power card to door fan D2h/D4h Wire harness, PCA to H/S fan & door/top fan – – – – – 1 1 1 1
CBL4 176F3322 Cable power card to CT D1h-D3h Wire harness, power card to CT/mixing fan 1 1 1 1 1 – – – –
CBL4 176F3323 Cable power card to CT D2h/D4h Wire harness, power card to CT/mixing fan – – – – – 1 1 1 1
CBL5 176F3324 Cable DC bus to power card D1h/D3h Wire harness, power card to DC bus 1 1 1 1 1 – – – –
CBL5 176F3325 Cable DC bus to power card D2h/D4h Wire harness, power card to DC bus – – – – – – – – –
CBL6 176F3326 Cable power card to HF/RFI D1h/D3h Wire harness, power card to RFI 1 1 1 1 1 – – – –
CBL6 176F3327 Cable power card to HF/RFI D2h/D4h Wire harness, power card to RFI – – – – – 1 1 1 1
CBL7 176F3328 Cable power card to gatedrive D1h/D3h Ribbon cable, power card to gatedrive card 1 1 1 1 1 – – – –
CBL7 176F3329 Cable power card to gatedrive D2h/D4h Ribbon cable, power card to gatedrive card – – – – – 1 1 1 1
CBL8 176F3331 Cable gatedrive to inrush D1h/D3h Ribbon cable, inrush card to gatedrive card 1 1 1 1 1 – – – –
CBL8 176F3332 Cable gatedrive to inrush D2h/D4h Ribbon cable, inrush card to gatedrive card – – – – – 1 1 1 1
CBL10 176F3333 Cable inrush to SCR gate D1h/D3h Wire harness, inrush card to SCR gates 1 1 1 1 1 – – – –
CBL10 176F3336 Cable inrush to SCR gate D2h/D4h Wire harness, inrush card to SCR gates – – – – – 1 1 1 1
CBL11 176F3179 Cable brake IGBT gate signal D1h D3h Wire harness, gatedrive card to brake IGBT 1 1 1 1 1 – – – –
CBL11 176F3180 Cable brake IGBT gate signal D2h D4h Wire harness, gatedrive card to brake IGBT – – – – – 1 1 1 1
CBL12 176F3177 Cable IGBT temp to gate PCA D1h D3h Wire harness, gatedrive card to IGBT NTC 1 1 1 1 1 – – – –
CBL12 176F3178 Cable IGBT temp to gate PCA D2h D4h Wire harness, gatedrive card to IGBT NTC – – – – – 1 1 1 1
CBL13 176F3175 Cable IGBT gate signal D1h D3h Wire harness, gatedrive card to IGBT gates 3 3 3 3 3 – – – –
CBL13 176F3176 Cable IGBT gate signal D2h D4h Wire harness, gatedrive card to IGBT gates – – – – – 3 3 3 3
Busbars
176F3338 Busbar SCR AC input D1h/D3h Busbars 3 3 3 3 3 – – – –
176F3339 Busbar DC+ inductor to cap bank D1h/D3h Busbars 1 1 1 1 1 – – – –
176F3340 Busbar DC- inductor to cap bank D1h/D3h Busbars 1 1 1 1 1 – – – –
176F3341 Busbar IGBT AC output D1h/D3h Busbars 3 3 3 3 3 – – – –
176F3346 Busbar assy SCR to DC coil D1h/D3h Busbars 1 1 1 1 1 – – – –
176F3347 Busbar assy curr sensor D1h/D3h Busbars 1 1 1 1 1 – – – –
176F6517 Busbar assy LEM 310A curr sensor D1h/D3h Busbars 1 1 1 1 1 – – – –
176F3356 Busbar motor terminals U,V,W D1h/D3h Busbars 1 1 1 1 1 – – – –
176F3357 Busbar mains, no fuse, no RFI D1h/D3h Busbars 1 1 1 1 1 – – – –
Spare Parts
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
342 Danfoss A/S © 02/2019 All rights reserved. MG94A502
