Danfoss VLT AutomationDrive FC 300 Series Service Guide

Block Diagram Name
Spare Part Number
Spare part name Comments 525–690 V AC (T7)
D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h
FC 102 N75k N90k N110 N132 N160 N200 N250 N315 N400 FC 103 N75k N90k N110 N132 N160 N200 N250 N315 N400
FC 202 N75k N90k N110 N132 N160 N200 N250 N315 N400
FC 302 N55k N75k N90k N110 N132 N160 N200 N250 N315
C4 176F3427 IGBT snubber cap 1250V 1.0 UF wide mount Snubber cap, brake IGBT – – – – – 1 1 1 1
Fans F2 176F3164 Heat sink fan DC 172x51 48VDC Heat sink fan 1 1 1 1 1 1 1 1 1 F1 176F3166 Top fan IP20 DC 80X25 48VDC IP20 top fan, fan only, 1 per kit IP20 IP20 IP20 IP20 IP20 – – – – F1 176F3167 Top fan IP20 DC 80X38 48VDC IP20 top fan, fan only, 1 per kit – – – – – IP20 IP20 IP20 IP20 F1 176F3168 Door fan IP21/54 DC 120X25 48VDC IP21/IP54 door fan, fan only, 1 per kit 21/54 21/54 21/54 21/54 21/54 – – – – F1 176F3169 Door fan IP21/54 DC 120X38 48VDC IP21/IP54 door fan, fan only, 1 per kit – – – – – 21/54 21/54 21/54 21/54 F3 176F3165 Mixing fan DC 40X28 24VDC Mixing fan, mounted below input terminals 1 1 1 1 1 1 1 1 1
Fuses FU1,2,3 176F3429 Fuse 160A 700V square body Mains fuse, 1 per kit 3 – – – – – – – –
FU1,2,3 176F3170 Fuse 315A 700V square body Mains fuse, 1 per kit – 3 3 3 3 – – – – FU1,2,3 176F3173 Fuse 550A 700V square body Mains fuse, 1 per kit – – – – – 3 3 3 3 Inductors and Current Sensors CT1,2,3 176F8342 Current sensor 300A Current sensor, 1 per kit 3 3 3 3 3 3 3 3 –
CT1,2,3 176F8343 Current sensor 500A Current sensor - see product note 244 – – – – – – – – 3
L1 176F3543 DC link coil small Dxh 181uH DC link inductor 1 1 1 1 1 – – – –
L1 176F5722 DC link coil large Dxh 140uH DC link inductor – – – – – 1 1 – –
L1 176F5721 DC link coil large Dxh 98uH DC link inductor – – – – – – – 1 – L1 176F5723 DC link coil large Dxh 78uH DC link inductor – – – – – – – – 1 Disconnects, Circuit Breakers, Contactors
SW1 176F3433 Disconnect 400A D1h power sizes Disconnect 1 1 1 1 1 – – – – SW1 176F3434 Disconnect 600A D2h power sizes Disconnect – – – – – 1 1 1 1 SW1 176F8348 Disconnect handle rod D2 enclosure Disconnect handle 1 1 1 1 1 1 1 1 1 SW1 176F3437 Circuit breaker 320A small D1h power Circuit breaker 1 1 1 1 1 – – – –
SW1 176F3439 Circuit breaker 480A small D2h power Circuit breaker – – – – – 1 1 1 –
SW1 176F3440 Circuit breaker 600A medium D2h power Circuit breaker – – – – – – – – 1
SW2 176F3435 Contactor 310A D1h power sizes Contactor 1 1 1 1 1 – – – – SW2 176F3436 Contactor 600A D2h power sizes Contactor – – – – – 1 1 1 1 Cables CBL1 176F3181 Cable LCP to control card D1h D3h DB9 extension cable assembly 1 1 1 1 1 – – – – CBL2 176F3183 Cable control card to power card D1h D3h Ribbon cable, control card to power card 1 1 1 1 1 – – – –
Spare Parts Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 341
15 15
