Spare part name Comments 525–690 V AC (T7)

D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h

FC 102 N75k N90k N110 N132 N160 N200 N250 N315 N400

FC 103 N75k N90k N110 N132 N160 N200 N250 N315 N400

FC 202 N75k N90k N110 N132 N160 N200 N250 N315 N400

FC 302 N55k N75k N90k N110 N132 N160 N200 N250 N315

PCA2 176F3499 Power card rugged NO 200kW 525-690V Conformal coated, without scaling card – – – – – T7 – – –

PCA2 176F3500 Power card rugged NO 250kW 525-690V Conformal coated, without scaling card – – – – – – T7 – –

PCA2 176F3501 Power card rugged NO 315kW 525-690V Conformal coated, without scaling card – – – – – – – T7 –

PCA2 176F3502 Power card rugged NO 400kW 525-690V Conformal coated, without scaling card – – – – – – – – T7

Other Printed Circuit Cards

PCA3 176F3411 Current scaling card 5.91 ohm 690V Installs on the power card 1 1 1 1 – – – – –

PCA3 176F3412 Current scaling card 5.00 ohm 690V Installs on the power card – – – – 1 – – – –

PCA3 176F3413 Current scaling card 4.02 ohm 690V Installs on the power card – – – – – 1 – – –

PCA3 176F3414 Current scaling card 3.20 ohm 690V Installs on the power card – – – – – – 1 – –

PCA3 176F3415 Current scaling card 2.67 ohm 690V Installs on the power card – – – – – – – 1 –

PCA3 176F3416 Current scaling card 5.62 ohm 690V Installs on the power card – – – – – – – – 1

PCA4 176F3417 Inrush card NO 75–400kW 690V Soft-charge/Inrush card 1 1 1 1 1 1 1 1 1

PCA4 176F3518 Inrush card rugged NO 75–400kW 690V Soft-charge/Inrush card 1 1 1 1 1 1 1 1 1

PCA5 176F3418 Gatedrive card NO 75–400kW 690V Gatedrive card 1 1 1 1 1 1 1 1 1

PCA5 176F3516 Gatedrive card rugged NO 75–400kW 690V Gatedrive card 1 1 1 1 1 1 1 1 1

PCA7 176F3419 Balance/HF card NO 75–400kW 690V DC bus cap balance/HF card 1 1 1 1 1 1 1 1 1

Semiconductors

SCR1,2,3 176F3426 Rectier SCR/diode 429A 2200V SCR/diode, 1 per kit – – – – – – – 3 3

SCR1,2,3 176F8529 Rectier SCR/diode 160A 2200V SCR/diode, 1 per kit 3 3 3 3 3 – – – –

SCR1,2,3 176F8530 Rectier SCR/diode 280A 2200V SCR/diode, 1 per kit – – – – – 3 3 – –

IGBT1,2,3 176F3422 IGBT dual module 300A 1700V IGBT module, 1 per kit 3 3 3 3 – – – – –

IGBT1,2,3 176F3423 IGBT dual module 450A 1700V IGBT module, 1 per kit – – – – 3 – – – –

IGBT1,2,3 176F3424 IGBT dual module 450A 1700V IGBT module, 1 per kit – – – – – 3 – – –

IGBT1,2,3 176F3425 IGBT dual module 650A 1700V IGBT module, 1 per kit – – – – – – 3 3 3

IGBT4 176F3366 IGBT brake module 450A 1700V IGBT module, 1 per kit brake brake brake brake brake – – – –

IGBT4 176F3367 IGBT brake module 650A 1700V IGBT module, 1 per kit – – – – – brake brake brake brake

Capacitors

CBANK1 176F3428 DC bus cap T7 drive single in housing DC bus cap, 385VDC, with black cup, 1 per kit 6 6 6 6 6 9 9 12 12

C1,C2,C3 176F8534 IGBT snubber cap 1250V 1.0 UF Snubber cap, IGBT 3 3 3 3 3 – – – –

C4 176F8534 IGBT snubber cap 1250V 1.0UF Snubber cap, brake IGBT 1 1 1 1 1 – – – –

C1,C2,C3 176F3427 IGBT snubber cap 1250V 1.0 UF wide mount Snubber cap, IGBT – – – – – 3 3 3 3

Spare Parts

VLT

FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
