Block

Diagram

Name

Spare

Part

Number

Spare part name Comments 525–690 V AC (T7)

D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h

FC 102 N75k N90k N110 N132 N160 N200 N250 N315 N400

FC 103 N75k N90k N110 N132 N160 N200 N250 N315 N400

FC 202 N75k N90k N110 N132 N160 N200 N250 N315 N400

FC 302 N55k N75k N90k N110 N132 N160 N200 N250 N315

Control Cards

PCA1 130B1151 Control Card, FC102 coated, no safe stop 102 102 102 102 102 102 102 102 102

PCA1 134B1730 Control Card, FC102 coated, no safe stop, Ver 2 card 102 102 102 102 102 102 102 102 102

PCA1 130B1150 Control Card, FC102 coated, safe stop 102 102 102 102 102 102 102 102 102

PCA1 134B1729 Control Card, FC102 coated, safe stop, Ver 2 card 102 102 102 102 102 102 102 102 102

PCA1 130B6968 Control Card, FC103 coated, no safe stop 103 103 103 103 103 103 103 103 103

PCA1 134B1724 Control Card, FC103 coated, no safe stop, Ver 2 card 103 103 103 103 103 103 103 103 103

PCA1 130B6967 Control Card, FC103 coated, safe stop 103 103 103 103 103 103 103 103 103

PCA1 134B1714 Control Card, FC103 coated, safe stop, Ver 2 card 103 103 103 103 103 103 103 103 103

PCA1 130B1168 Control Card, FC202 coated, no safe stop 202 202 202 202 202 202 202 202 202

PCA1 134B1732 Control Card, FC202 coated, no safe stop, Ver 2 card 202 202 202 202 202 202 202 202 202

PCA1 130B1167 Control Card, FC202 coated, safe stop 202 202 202 202 202 202 202 202 202

PCA1 134B1731 Control Card, FC202 coated, safe stop, Ver 2 card 202 202 202 202 202 202 202 202 202

PCA1 130B1109 Control Card, FC302 coated, safe stop 302 302 302 302 302 302 302 302 302

PCA1 134B1726 Control Card, FC302 coated, safe stop, Ver 2 card 302 302 302 302 302 302 302 302 302

Power Cards

PCA2 176F3420 Power card NO 75kW 525–690V Conformal coated, without scaling card T7 – – – – – – – –

PCA2 176F3421 Power card NO 90kW 525–690V Conformal coated, without scaling card – T7 – – – – – – –

PCA2 176F3152 Power card NO 110kW 525–690V Conformal coated, without scaling card – – T7 – – – – – –

PCA2 176F3146 Power card NO 132kW 525–690V Conformal coated, without scaling card – – – T7 – – – – –

PCA2 176F3147 Power card NO 160kW 525–690V Conformal coated, without scaling card – – – – T7 – – – –

PCA2 176F3148 Power card NO 200kW 525–690V Conformal coated, without scaling card – – – – – T7 – – –

PCA2 176F3149 Power card NO 250kW 525–690V Conformal coated, without scaling card – – – – – – T7 – –

PCA2 176F3150 Power card NO 315kW 525–690V Conformal coated, without scaling card – – – – – – – T7 –

PCA2 176F3151 Power card NO 400kW 525–690V Conformal coated, without scaling card – – – – – – – – T7

PCA2 176F3494 Power card rugged NO 75kW 525–690V Conformal coated, without scaling card T7 – – – – – – – –

PCA2 176F3495 Power card rugged NO 90kW 525–690V Conformal coated, without scaling card – T7 – – – – – – –

PCA2 176F3496 Power card rugged NO 110kW 525-690V Conformal coated, without scaling card – – T7 – – – – – –

PCA2 176F3497 Power card rugged NO 132kW 525-690V Conformal coated, without scaling card – – – T7 – – – – –

PCA2 176F3498 Power card rugged NO 160kW 525-690V Conformal coated, without scaling card – – – – T7 – – – –

Spare Parts Service Guide

15 15
