Block Diagram Name
Spare Part Number
Spare part name Comments 380–500 V AC (T4/T5)
D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h
FC 102 (T4) N110 N132 N160 N200 N250 N315 FC 103 (T4) N110 N132 N160 N200 N250 N315
FC 202 (T4) N110 N132 N160 N200 N250 N315 FC 302 (T5) N90k N110 N132 N160 N200 N250
176F3540 Heat sink fan cover Dxh enclosures Enclosure 1 1 1 1 1 1
176F3548 Cover DC link coil large Dxh enclosure Enclosure – – – 1 1 1 176F3549 Cover DC link coil small Dxh enclosure Enclosure 1 1 1 – – –
176F5000 Anti-condensation heater Dxh enclosure Resistor 1 1 1 1 1 1 176F5734 Front cover IP21/IP54 D1h enclosure Enclosure 21/54 21/54 21/54 – – –
176F5735 Front cover IP21/IP54 D2h enclosure Enclosure – – – 21/54 21/54 21/54 176F5736 Front cover no LCP IP21/54 D1h enclosure Enclosure 21/54 21/54 21/54 – – –
176F5737 Front cover no LCP IP21/54 D2h enclosure Enclosure – – – 21/54 21/54 21/54
176F5739 Extended option adapter plate D1h enclosure Enclosure 1 1 1 – – –
176F5740 Extended option adapter plate D2h enclosure Enclosure – – – 1 1 1
176F5741 Gland plate D1h enclosure Enclosure 21/54 21/54 21/54 – – – 176F5742 Gland plate D2h enclosure Enclosure – – – 21/54 21/54 21/54 176F5748 Top plate assembly D4h Enclosure – – – IP20 IP20 IP20 176F5747 Enclosure left side D4h Enclosure – – – IP20 IP20 IP20 176F5749 Enclosure right side D4h Enclosure – – – IP20 IP20 IP20
176F6304 Front cover D2 w/ disconnect short cab. Enclosure – – – 21/54 21/54 21/54
Table 15.9 Spare Parts List, D1h–D8h Drives, 380–500 V AC (T4/T5)
Spare Parts
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
338 Danfoss A/S © 02/2019 All rights reserved. MG94A502
