Block

Diagram

Name

Spare

Part

Number

Spare part name Comments 380–500 V AC (T4/T5)

D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h

FC 102 (T4) N110 N132 N160 N200 N250 N315

FC 103 (T4) N110 N132 N160 N200 N250 N315

FC 202 (T4) N110 N132 N160 N200 N250 N315

FC 302 (T5) N90k N110 N132 N160 N200 N250

176F3381 Busbar DC- SCR to DC coil D2h/D4h Busbars – – – 1 1 1

176F3382 Busbar DC+ inductor to cap bank D2h/D4h Busbars – – – 1 1 1

176F3383 Busbar DC- inductor to cap bank D2h/D4h Busbars – – – 1 1 1

176F3384 Busbar IGBT AC output D2h/D4h Busbars – – – 3 3 3

176F3385 Busbar assy current sensor D2h/D4h Busbars – – – 1 1 1

176F3386 Busbar assy cap bank 400V D2h/D4h Busbars – – – 1 1 1

Other Parts

176F3353 Door fan lter Dxh enclosure, package of 10 Fan lter 21/54 21/54 21/54 21/54 21/54 21/54

176F3342 Air bae D2h enclosure Enclosure – – – 21/54 21/54 21/54

176F3343 Air bae D4h enclosure Enclosure – – – IP20 IP20 IP20

176F3345 Cable clamp 45mm Dxh enclosure Enclosure 4 4 4 – – –

176F3351 Air bae D3h enclosure Enclosure IP20 IP20 IP20 – – –

176F3352 Air bae D1h enclosure Enclosure 21/54 21/54 21/54 – – –

176F3375 Door vent kit IP21/IP54 Dxh enclosure Enclosure 21/54 21/54 21/54 21/54 21/54 21/54

176F3389 Front cover IP20 D4h enclosure Enclosure – – – IP20 IP20 IP20

176F3390 Front cover IP20 D3h enclosure Enclosure IP20 IP20 IP20 – – –

176F3479 Power terminal cover IP20 D3h enclosure Enclosure IP20 IP20 IP20 – – –

176F3480 Power terminal cover IP20 D4h enclosure Enclosure – – – IP20 IP20 IP20

176F3481 Mains shield D1h enclosure Enclosure 21/54 21/54 21/54 – – –

176F3482 Mains shield D2h enclosure Enclosure – – – 21/54 21/54 21/54

176F8430 Cable clamp for enclosure size D & E Enclosure – – – 4 4 4

130B0264 Cradle for A5,B1,B2,C1 and C2 enclosure Insulation – – – 1 1 1

176F3344 Bracket gatedrive support D2h/D4h Insulation – – – 1 1 1

176F3348 Bracket inrush support D1h/D3h Insulation 1 1 1 – – –

176F3349 Bracket gatedrive support D1h/D3h Insulation 1 1 1 – – –

176F3354 Insulation mains terminals D1h/D3h Insulation 1 1 1 – – –

176F3355 Insulation motor terminals D1h/D3h Insulation 1 1 1 – – –

176F3361 Bracket inrush support D2h/D4h DC bus standos, includes 2 – – – 1 1 1

176F3369 Mains terminals D2h/D4h Insulation – – – 1 1 1

176F3370 Motor terminals D2h/D4h Insulation – – – 1 1 1

176F3388 Cradle for LCP D1h/D3h enclosure Insulation 1 1 1 – – –

Spare Parts Service Guide

15 15
