Spare part name Comments 380–500 V AC (T4/T5)

D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h

FC 102 (T4) N110 N132 N160 N200 N250 N315

FC 103 (T4) N110 N132 N160 N200 N250 N315

FC 202 (T4) N110 N132 N160 N200 N250 N315

FC 302 (T5) N90k N110 N132 N160 N200 N250

CBL10 176F3336 Cable inrush to SCR gate D2h/D4h Wire harness, inrush card to SCR gates – – – 1 1 1

CBL11 176F3179 Cable brake IGBT gate signal D1h D3h Wire harness, gatedrive card to brake IGBT, 1 per kit 1 1 1 – – –

CBL11 176F3180 Cable brake IGBT gate signal D2h D4h Wire harness, gatedrive card to brake IGBT, 1 per kit – – – 1 1 1

CBL12 176F3177 Cable IGBT temp to gate PCA D1h D3h Wire harness, gatedrive card to IGBT NTC, 1 per kit 1 1 1 – – –

CBL12 176F3178 Cable IGBT temp to gate PCA D2h D4h Wire harness, gatedrive card to IGBT NTC, 1 per kit – – – 1 1 1

CBL13 176F3175 Cable IGBT gate signal D1h D3h Wire harness, gatedrive card to IGBT gates, 1 per kit 3 3 3 – – –

CBL13 176F3176 Cable IGBT gate signal D2h D4h Wire harness, gatedrive card to IGBT gates, 1 per kit – – – 3 3 3

Busbars

176F3338 Busbar SCR AC input D1h/D3h Busbars 3 3 3 – – –

176F3339 Busbar DC+ inductor to cap bank D1h/D3h Busbars 1 1 1 – – –

176F3340 Busbar DC- inductor to cap bank D1h/D3h Busbars 1 1 1 – – –

176F3341 Busbar IGBT AC output D1h/D3h Busbars 3 3 3 – – –

176F3346 Busbar assy SCR to DC coil D1h/D3h Busbars 1 1 1 – – –

176F3347 Busbar assy curr sens D1h/D3h Busbars 1 1 1 – – –

176F6517 Busbar assy LEM 310A curr sens D1h/D3h Busbars 1 1 1 – – –

176F3350 Busbar assy cap bank 400V D1h/D3h Busbars 1 1 1 – – –

176F3356 Busbar motor terminals U,V,W D1h/D3h Busbars 1 1 1 – – –

176F3357 Busbar mains, no fuse, no RFI D1h/D3h Busbars 1 1 1 – – –

176F3358 Busbar mains, fuse, no RFI D1h/D3h Busbars 1 1 1 – – –

176F3359 Busbar mains, RFI, no fuse D1h/D3h Busbars 1 1 1 – – –

176F3360 Busbar mains, fuse, RFI D1h/D3h Busbars 1 1 1 – – –

176F3368 Busbar motor terminals U,V,W D2h/D4h Busbars – – – 1 1 1

176F3371 Busbar mains, no fuse, no RFI D2h/D4h Busbars – – – 1 1 1

176F3372 Busbar mains, fuse, no RFI D2h/D4h Busbars – – – 1 1 1

176F3373 Busbar mains, RFI, no fuse D2h/D4h Busbars – – – 1 1 1

176F3374 Busbar mains, fuse, RFI D2h/D4h Busbars – – – 1 1 1

176F3376 Busbar SCR AC input small D2h/D4h Busbars – – – 3 3 –

176F3377 Busbar SCR AC input large D2h/D4h Busbars - see product note 185 – – – – – 3

176F3378 Busbar SCR DC output small D2h/D4h Busbars – – – 2 2 –

176F3379 Busbar SCR DC output large D2h/D4h Busbars - see product note 185 – – – – – 2

176F3380 Busbar DC+ SCR to DC coil D2h/D4h Busbars – – – 1 1 1
