Block
Diagram
Name
Spare
Part
Number
Spare part name Comments 380–500 V AC (T4/T5)
D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h
FC 102 (T4) N110 N132 N160 N200 N250 N315
FC 103 (T4) N110 N132 N160 N200 N250 N315
FC 202 (T4) N110 N132 N160 N200 N250 N315
FC 302 (T5) N90k N110 N132 N160 N200 N250
L1 176F5723 DC link coil large Dxh 78uH DC inductor – – – – 1 –
L1 176F5724 DC link coil large Dxh 65uH DC inductor – – – – – 1
Disconnects
SW1 176F3433 Disconnect 400A D1h power sizes Disconnect 1 1 1 – – –
SW1 176F3434 Disconnect 600A D2h power sizes Disconnect – – – 1 1 1
SW1 176F8348 Disconnect handle rod D2 enclosure Disconnect handle 1 1 1 1 1 1
Circuit Breakers and Contactors
SW1 176F3437 Circuit breaker 320A small D1h power Circuit breaker 1 1 – – – –
SW1 176F3438 Circuit breaker 400A large D1h power Circuit breaker – – 1 – – –
SW1 176F3439 Circuit breaker 480A small D2h power Circuit breaker – – – 1 – –
SW1 176F3440 Circuit breaker 600A medium D2h power Circuit breaker – – – – 1 –
SW1 176F3441 Circuit breaker 800A large D2h power Circuit breaker – – – – – 1
SW2 176F3435 Contactor 310A D1h power sizes Contactor 1 1 1 – – –
SW2 176F3436 Contactor 600A D2h power sizes Contactor – – – 1 1 1
Cables
CBL1 176F3181 Cable LCP to control card D1h D3h DB9 extension cable assembly 1 1 1 – – –
CBL2 176F3183 Cable control card to power card D1h D3h Ribbon cable, control card to power card 1 1 1 – – –
CBL2 176F3319 Cable control card to power card D2h/D4h Ribbon cable, control card to power card – – – 1 1 1
CBL3 176F3320 Cable power card to door fan D1h/D3h Wire harness, power card to H/S fan & door/top fan 1 1 1 – – –
CBL3 176F3321 Cable power card to door fan D2h/D4h Wire harness, power card to H/S fan & door/top fan – – – 1 1 1
CBL4 176F3322 Cable power card to CT D1h/D3h Wire harness, power card to current sensors/mix fan 1 1 1 – – –
CBL4 176F3323 Cable power card to CT D2h/D4h Wire harness, power card to current sensors/mix fan – – – 1 1 1
CBL5 176F3324 Cable DC bus to power card D1h/D3h Wire harness, power card to DC bus 1 1 1 – – –
CBL5 176F3325 Cable DC bus to power card D2h/D4h Wire harness, power card to DC bus 1 1 1 1 1 1
CBL6 176F3326 Cable power card to HF/RFI D1h/D3h Wire harness, power card to RFI 1 1 1 – – –
CBL6 176F3327 Cable power card to HF/RFI D2h/D4h Wire harness, power card to RFI – – – 1 1 1
CBL7 176F3328 Cable power card to gatedrive D1h/D3h Ribbon cable, power card to gatedrive card 1 1 1 – – –
CBL7 176F3329 Cable power card to gatedrive D2h/D4h Ribbon cable, power card to gatedrive card – – – 1 1 1
CBL8 176F3331 Cable gatedrive to inrush D1h/D3h Ribbon cable, inrush card to gatedrive card 1 1 1 – – –
CBL8 176F3332 Cable gatedrive to inrush D2h/D4h Ribbon cable, inrush card to gatedrive card – – – 1 1 1
CBL10 176F3333 Cable inrush to SCR gate D1h/D3h Wire harness, inrush card to SCR gates 1 1 1 – – –
Spare Parts Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 335
