Block

Diagram

Name

Spare

Part

Number

Spare part name Comments 380–500 V AC (T4/T5)

D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h

FC 102 (T4) N110 N132 N160 N200 N250 N315

FC 103 (T4) N110 N132 N160 N200 N250 N315

FC 202 (T4) N110 N132 N160 N200 N250 N315

FC 302 (T5) N90k N110 N132 N160 N200 N250

IGBT 4 176F3366 IGBT brake module 450A 1700V IGBT module, 1 per kit brake brake brake – – –

IGBT 4 176F3367 IGBT brake module 650A 1700V IGBT module, 1 per kit – – – brake brake brake

Capacitors

CBank 1 176F3163 DC bus cap 4700UF 450V single in housing DC bus capacitor, 450VDC, includes black cup, 1 per kit 4 6 6 8 10 12

C1, C2, C3 176F8323 IGBT snubber cap 1000V 1.5UF Snubber capacitor 3 3 3 – – –

C4 176F8534 IGBT snubber cap 1250V 1.0UF Snubber capacitor, brake IGBT 1 1 1 – – –

C1, C2, C3 176F3162 IGBT snubber cap 1000V 1.5UF wide mount Snubber capacitor – – – 3 3 3

C4 176F3427 IGBT snubber cap 1250V 1.0UF wide mount Snubber capacitor, brake IGBT – – – 1 1 1

Fans

F2 176F3164 Heat sink fan DC 172x51 48VDC Heat sink fan 1 1 1 1 1 1

F1 176F3166 Top fan IP20 DC 80X25 48VDC IP20 top fan, fan only IP20 IP20 IP20 – – –

F1 176F3167 Top fan IP20 DC 80X38 48VDC IP20 top fan, fan only – – – IP20 IP20 IP20

F1 176F3168 Door fan IP21/54 DC 120X25 IP21/IP54 door fan, fan only, 1 fan 21/54 21/54 21/54 – – –

F1 176F3169 Door fan IP21/54 DC 120X38 IP21/IP54 door fan, fan only, 1 fan – – – 21/54 21/54 21/54

F3 176F3165 Mixing fan DC 40X28 - 24VDC Mixing fan, mounted below the input terminals 1 1 1 1 1 1

Fuses

FU 1,2,3 176F3170 Fuse 315A 700V square body Mains fuses, 1 per kit 3 – – – – –

FU 1,2,3 176F3171 Fuse 350A 700V square body Mains fuses, 1 per kit – 3 – – – –

FU 1,2,3 176F3172 Fuse 400A 700V square body Mains fuses, 1 per kit – – 3 – – –

FU 1,2,3 176F3173 Fuse 550A 700V square body Mains fuses, 1 per kit – – – 3 – –

FU 1,2,3 176F3174 Fuse 800A 700V square body Mains fuses, 1 per kit – – – – – 3

FU 1,2,3 176F8335 Fuse ultra fast 630A 700V Mains fuses, 1 per kit – – – – 3 –

Inductors and Current Sensors

CT 1,2,3 176F8342 Current sensor 300A Current sensor - see product note 244 – – – – – –

CT 1,2,3 176F8343 Current sensor 500A Current sensor - see product note 244 – – – – – –

CT 1,2,3 176F6515 Current sensor 300A - LEM Current sensor - used after week 3 2016 3 3 3 3 – –

CT 1,2,3 176F6447 Current sensor 500A - LEM Current sensor - used after week 3 2016 – – – – 3 3

L1 176F3543 DC link coil small Dxh 181uH DC inductor 1 – – – – –

L1 176F3544 DC link coil small Dxh 140uH DC inductor – 1 – – – –

L1 176F3545 DC link coil small Dxh 122uH DC inductor – – 1 – – –

L1 176F5721 DC link coil large Dxh 98uH DC inductor – – – 1 – –

Spare Parts

VLT

FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9

1515
