Block

Diagram

Name

Spare

Part

Number

Spare part name Comments 380–500 V AC (T4/T5)

D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h

FC 102 (T4) N110 N132 N160 N200 N250 N315

FC 103 (T4) N110 N132 N160 N200 N250 N315

FC 202 (T4) N110 N132 N160 N200 N250 N315

FC 302 (T5) N90k N110 N132 N160 N200 N250

PCA2 176F3512 Power card rugged NO 200kW 380–480V Conformal coated, does not include scaling card – – – T4 – –

PCA2 176F3513 Power card rugged NO 250kW 380–480V Conformal coated, does not include scaling card – – – – T4 –

PCA2 176F3514 Power card rugged NO 315kW 380–480V Conformal coated, does not include scaling card – – – – – T4

PCA2 176F3503 Power card rugged NO 110kW 380–500V Conformal coated, does not include scaling card T5 – – – – –

PCA2 176F3504 Power card rugged NO 132kW 380–500V Conformal coated, does not include scaling card – T5 – – – –

PCA2 176F3505 Power card rugged NO 160kW 380–500V Conformal coated, does not include scaling card – – T5 – – –

PCA2 176F3506 Power card rugged NO 200kW 380–500V Conformal coated, does not include scaling card – – – T5 – –

PCA2 176F3507 Power card rugged NO 250kW 380–500V Conformal coated, does not include scaling card – – – – T5 –

PCA2 176F3508 Power card rugged NO 315kW 380–500V Conformal coated, does not include scaling card – – – – – T5

Other Printed Circuit Cards

PCA3 176F3153 Current scaling card 4.57 ohm 400V Installs on the power card 1 – – – – –

PCA3 176F3154 Current scaling card 3.82 ohm 400V Installs on the power card – 1 – – – –

PCA3 176F3155 Current scaling card 3.11 ohm 400V Installs on the power card – – 1 – – –

PCA3 176F3156 Current scaling card 2.56 ohm 400V Installs on the power card – – – 1 – –

PCA3 176F3157 Current scaling card 5.10 ohm 400V Installs on the power card – – – – 1 –

PCA3 176F3158 Current scaling card 4.22 ohm 400V Installs on the power card – – – – – 1

PCA4 176F3159 Inrush card NO 110–315kW 400V Soft-charge/inrush card 1 1 1 1 1 1

PCA4 176F3517 Inrush card rugged NO 110–315kW 400V Soft-charge/inrush card 1 1 1 1 1 1

PCA5 176F3160 Gatedrive card NO 110–315kW 400V Gatedrive card 1 1 1 1 1 1

PCA5 176F3515 Gatedrive card rugged NO 110–315kW 400V Gatedrive card 1 1 1 1 1 1

PCA5 176F6300 Gatedrive card special version Gatedrive card - S056 variant 1 1 1 1 1 1

PCA6 176F3387 RFI card NO 110–315kW 400V RFI class A1 board 1 1 1 1 1 1

PCA7 176F3161 Balance/HF card NO 110–315kW 400V DC bus cap balance/high frequency card 1 1 1 1 1 1

Semiconductors

SCR 1,2,3 176F3337 Rectier SCR/diode 503A 1600V SCR/diode, 1 per kit – see product note 185 – – – – 3 3

SCR 1,2,3 176F8318 Rectier SCR/diode 175A 1600V SCR/diode, 1 per kit 3 3 3 – – –

SCR 1,2,3 176F8320 Rectier SCR/diode 330A 1600V SCR/diode, 1 per kit, includes stando to inrush card – – – 3 3 –

IGBT 1,2,3 176F3362 IGBT dual module 300A 1200V IGBT module, 1 per kit 3 – – – – –

IGBT 1,2,3 176F3363 IGBT dual module 450A 1200V IGBT module, 1 per kit – 3 3 – – –

IGBT 1,2,3 176F3364 IGBT dual module 600A 1200V IGBT module, 1 per kit – – – 3 – –

IGBT 1,2,3 176F3365 IGBT dual module 900A 1200V IGBT module, 1 per kit – – – – 3 3

Spare Parts Service Guide

15 15
