Block

Diagram

Name

Spare

Part

Number

Spare part name Comments 380–500 V AC (T4/T5)

D1h/D3h/D5h/D6h D2h/D4h/D7h/D8h

FC 102 (T4) N110 N132 N160 N200 N250 N315

FC 103 (T4) N110 N132 N160 N200 N250 N315

FC 202 (T4) N110 N132 N160 N200 N250 N315

FC 302 (T5) N90k N110 N132 N160 N200 N250

Control Cards

PCA1 130B1151 Control Card, FC102 Coated, no safe stop 102 102 102 102 102 102

PCA1 134B1730 Control Card, FC102 Coated, no safe stop, Ver 2 card 102 102 102 102 102 102

PCA1 130B1150 Control Card, FC102 Coated, safe stop 102 102 102 102 102 102

PCA1 134B1729 Control Card, FC102 Coated, safe stop, Ver 2 card 102 102 102 102 102 102

PCA1 130B6968 Control Card, FC103 Coated, no safe stop 103 103 103 103 103 103

PCA1 134B1724 Control Card, FC103 Coated, no safe stop, Ver 2 card 103 103 103 103 103 103

PCA1 130B6967 Control Card, FC103 Coated, safe stop 103 103 103 103 103 103

PCA1 134B1714 Control Card, FC103 Coated, safe stop, Ver 2 card 103 103 103 103 103 103

PCA1 130B1168 Control Card, FC202 Coated, no safe stop 202 202 202 202 202 202

PCA1 134B1732 Control Card, FC202 Coated, no safe stop, Ver 2 card 202 202 202 202 202 202

PCA1 130B1167 Control Card, FC202 Coated, safe stop 202 202 202 202 202 202

PCA1 134B1731 Control Card, FC202 Coated, safe stop, Ver 2 card 202 202 202 202 202 202

PCA1 130B1109 Control Card, FC302 Coated, safe stop 302 302 302 302 302 302

PCA1 134B1726 Control Card, FC302 Coated, safe stop, Ver 2 card 302 302 302 302 302 302

Power Cards

PCA2 176F3134 Power card NO 110kW 380–480V Conformal coated, does not include scaling card T4 – – – – –

PCA2 176F3135 Power card NO 132kW 380–480V Conformal coated, does not include scaling card – T4 – – – –

PCA2 176F3136 Power card NO 160kW 380–480V Conformal coated, does not include scaling card – – T4 – – –

PCA2 176F3137 Power card NO 200kW 380–480V Conformal coated, does not include scaling card – – – T4 – –

PCA2 176F3138 Power card NO 250kW 380–480V Conformal coated, does not include scaling card – – – – T4 –

PCA2 176F3139 Power card NO 315kW 380–480V Conformal coated, does not include scaling card – – – – – T4

PCA2 176F3140 Power card NO 110kW 380–500V Conformal coated, does not include scaling card T5 – – – – –

PCA2 176F3141 Power card NO 132kW 380–500V Conformal coated, does not include scaling card – T5 – – – –

PCA2 176F3142 Power card NO 160kW 380–500V Conformal coated, does not include scaling card – – T5 – – –

PCA2 176F3143 Power card NO 200kW 380–500V Conformal coated, does not include scaling card – – – T5 – –

PCA2 176F3144 Power card NO 250kW 380–500V Conformal coated, does not include scaling card – – – – T5 –

PCA2 176F3145 Power card NO 315kW 380–500V Conformal coated, does not include scaling card – – – – – T5

PCA2 176F3509 Power card rugged NO 110kW 380–480V Conformal coated, does not include scaling card T4 – – – – –

PCA2 176F3510 Power card rugged NO 132kW 380–480V Conformal coated, does not include scaling card – T4 – – – –

PCA2 176F3511 Power card rugged NO 160kW 380–480V Conformal coated, does not include scaling card – – T4 – – –

Spare Parts

VLT

FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9

1515
