Spare Part Name Comments 200–240 V AC

D1h/D3h D2h/D4h

FC 102 (T2) N55K N75K N90K N100 N150 N160

FC 202 (T2) N55K N75K N90K N100 N150 N160

FC 302 (T2) N45K N55K N75K N90K N100 N150

130B0264 Cradle for A5,B1,B2,C1 and C2 encl insulation – – – 1 1 1

176F3344 Bracket gate drive support D2h/D4h insulation – – – 1 1 1

176F3348 Bracket Inrush support D1h/D3h insulation 1 1 1 – – –

176F3349 Bracket gate drive support D1h/D3h insulation 1 1 1 – – –

176F3354 Insulation mains terminals D1h/D3h insulation 1 1 1 – – –

176F3355 Insultation motor terminals D1h/D3h insulation 1 1 1 – – –

176F3361 Bracket Inrush support D2h/D4h Includes 2 DC bus standos - 177G3920 – – – 1 1 1

176F3369 Mains terminals D2h/D4h insulation – – – 1 1 1

176F3370 Motor terminals D2h/D4h insulation – – – 1 1 1

176F3388 Cradle for LCP D1h/D3h encl insulation 1 1 1 – – –

176F3540 Heatsink Fan Cover Dh frames enclosure 1 1 1 1 1 1

176F3548 Cover DC Link Coil Large Dh frame enclosure – – – 1 1 1

176F3549 Cover DC Link Coil Small Dh frame enclosure 1 1 1 – – –

176F5000 Anti Condensation Heater Dh frame resistor 1 1 1 1 1 1

176F5734 Front Cover IP21/IP54 D1h encl enclosure 21/54 21/54 21/54 – – –

176F5735 Front Cover IP21/IP54 D2h encl enclosure – – – 21/54 21/54 21/54

176F5736 Front Cover No LCP IP21/54 D1h encl enclosure 21/54 21/54 21/54 – – –

176F5737 Front Cover No LCP IP21/54 D2h encl enclosure – – – 21/54 21/54 21/54

176F5739 Extended Option Adaptor Plate D1h frame enclosure 1 1 1 – – –

176F5740 Extended Option Adaptor Plate D2h frame enclosure – – – 1 1 1

176F5741 Gland Plate D1h frame enclosure 21/54 21/54 21/54 – – –

176F5742 Gland Plate D2h frame enclosure – – – 21/54 21/54 21/54

176F5748 Top Plate Assembly D4h enclosure – – – IP20 IP20 IP20

176F5747 Enclosure Left Side D4h enclosure – – – IP20 IP20 IP20

176F5749 Enclosure Right Side D4h enclosure – – – IP20 IP20 IP20

176F6304 Front Cover D2 w/ Disconnect Short Cab. enclosure – – – 21/54 21/54 21/54

Table 15.8 Spare Parts List, D1h–D4h Drives, 200–240 V AC (T2)
