Danfoss VLT AutomationDrive FC 300 Series Service Guide

Block Diagram Name
Spare Part Number
Spare part name Comments 380–480/500 VAC (T4/T5)
E1h/E3h E2h/E4h
FC 102 (T4) N355 N400 N450 N500 N560 FC 103 (T4) N355 N400 N450 N500 N560 FC 202 (T4) N355 N400 N450 N500 N560 FC 302 (T5) N315 N355 N400 N450 N500
Control Cards PCA1 130B1151 Control Card, FC102 coated, no safe stop 102 102 102 102 102
PCA1 134B1730 Control Card, FC102 coated, no safe stop, Ver 2 card 102 102 102 102 102
PCA1 130B1150 Control Card, FC102 coated, safe stop 102 102 102 102 102 PCA1 134B1729 Control Card, FC102 coated, safe stop, Ver 2 card 102 102 102 102 102
PCA1 130B6968 Control Card, FC103 coated, no safe stop 103 103 103 103 103
PCA1 134B1724 Control Card, FC103 coated, no safe stop, Ver 2 card 103 103 103 103 103
PCA1 130B6967 Control Card, FC103 coated, safe stop 103 103 103 103 103
PCA1 134B1714 Control Card, FC103 coated, safe stop, Ver 2 card 103 103 103 103 103
PCA1 130B1168 Control Card, FC202 coated, no safe stop 202 202 202 202 202
PCA1 134B1732 Control Card, FC202 coated, no safe stop, Ver 2 card 202 202 202 202 202
PCA1 130B1167 Control Card, FC202 coated, safe stop 202 202 202 202 202
PCA1 134B1731 Control Card, FC202 coated, safe stop, Ver 2 card 202 202 202 202 202
PCA1 130B1109 Control Card, FC302 coated, safe stop 302 302 302 302 302
PCA1 134B1726 Control Card, FC302 coated, safe stop, Ver 2 card 302 302 302 302 302
Printed Circuit Cards
PCA2 176F6625 Power card high power S/W preloaded, all power sizes, conformal coated, no scaling card 1 1 1 1 1
PCA3 176F3415 Current scaling card 2.67 ohm Installs on the power card 1 – – – –
PCA3 176F6628 Current scaling card 2.45 ohm Installs on the power card – 1 – – –
PCA3 176F6629 Current scaling card 2.18 ohm Installs on the power card – – 1 – –
PCA3 176F6630 Current scaling card 2.02 ohm Installs on the power card – – – 1 –
PCA3 176F6631 Current scaling card 1.83 ohm Installs on the power card – – – – 1 PCA4 176F6623 Inrush card 400V Mounts on the SCR/diode modules 1 1 1 1 1 PCA5 176F6621 Gatedrive card 400V Gatedrive card includes brake 1 1 1 1 1
PCA6A 176F6626 RFI card di high power Circuit board in the RFI lter 1 1 1 1 1
PCA7 176F3161 Balance/HF card NO 110-560kW 400V Combined high frequency and balance card 1 1 1 1 1
PCA16 176F6638 Fan power card high power Fan power card for E-sized drives 1 1 1 1 1
Semiconductors
IGBT1,2,3,4,5,6 176F6641 IGBT module 600A T4/T5 IGBT module, 1 per kit 6 6 6 – – IGBT1,2,3,4,5,6 176F6642 IGBT module 900A T4/T5 IGBT module, 1 per kit – – – 6 6
IGBT7,8 176F6645 IGBT brake module 450A E1,E3 Brake IGBT module, 1 per kit 2 2 2 – –
Spare Parts
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
346 Danfoss A/S © 02/2019 All rights reserved. MG94A502
