Block
Diagram
Name
Spare
Part
Number
Spare part name Comments 380–480/500 VAC (T4/T5)
E1h/E3h E2h/E4h
FC 102 (T4) N355 N400 N450 N500 N560
FC 103 (T4) N355 N400 N450 N500 N560
FC 202 (T4) N355 N400 N450 N500 N560
FC 302 (T5) N315 N355 N400 N450 N500
IGBT7,8 176F6646 IGBT brake module 450A E2,E4 Brake IGBT module, 1 per kit – – – 2 2
SCR1,2,3 176F6647 Rectier SCR/diode 700AMP 1600V SCR/diode, 1 per kit 3 3 3 3 3
Capacitors
CBANK1 176F6634 Capacitor T5 Individual DC bus capacitor, 1 per kit 14 16 16 20 20
C1,2,3,4,5,6 176F8323 IGBT snubber cap 1000V 1.5UF IGBT snubber cap, mounts on IGBT modules 6 6 6 – –
C1,2,3,4,5,6 176F3162 IGBT snubber cap 1000V 1.5uF wide mount IGBT snubber cap, mounts on IGBT modules – – – 6 6
Fans
F2 176F6637 Fan, heat sink, UL 12 P4001 Fan, heat sink, high speed, 172X51mm, 48VDC 3 3 3 3 3
F1 176F3167 Top fan IP20 DC 80X38 48VDC Fan, IP20, door, 80x38mm, 48VDC 2 2 2 2 2
F4 176F6636 Fan, top/door P4001 E1h–E4h Door fan, E1h–E4h, 120X38mm, 48VDC 2 2 2 2 2
Fuses
FU1,2,3 176F6639 Fuse, main, 1250A, 700V Mains fuse, 1 per kit 3 3 3 3 3
Inductors and Current Sensors
CT1,2,3 176F6633 Current sensor 1000A LEM LF1010-S-SPA1, 1 per kit 3 3 3 3 3
L1 176F6730 DC link coil 47uH DC inductor 1 – – – –
L1 176F6731 DC link coil 42uH DC inductor – 1 1 – –
L1 176F6732 DC link coil 28uH DC inductor – – – 1 1
Disconnects
SW1 176F6315 Switch, disc,800A,690V Main disconnect 1 1 1 – –
SW1 176F6735 Switch, disc,1200A,690V Main disconnect – – – 1 1
SW1 176F9189 Double disc, handle & rod E frm LHD/AAF Double disc handle & 12x165 mm shaft 1 1 1 1 1
Cables
CBL1 176F3181 Cable LCP to control card D1h D3h DB9 extension cable assembly 1 1 1 1 1
CBL2 176F3183 Cable control card to power card D1H D3H Cable, control card to power card 1 1 1 1 1
CBL3 176F6651 Assy, wire, CBL3, P4001 ,pwr-mixing, E1 Wire harness, power card to mixing fans 1 1 1 – –
CBL3 176F6652 Assy, wire, CBL3, P4001, pwr-mixing, E2 Wire harness, power card to mixing fans – – – 1 1
CBL4 176F6653 Assy, wire, CBL4, P4001, pwr-CT, E1h Wire harness, power card to current sensors 1 1 1 – –
CBL4 176F6654 Assy, wire, CBL4, P4001, pwr-CT, E2h Wire harness, power card to current sensors – – – 1 1
CBL5 176F6693 Assy, wire, CBL5, P4001, DC-pwr, E1h Wire harness, DC bus to fan power supply 1 1 1 – –
CBL5 176F6694 Assy, wire, CBL5, P4001, DC-pwr, E2h Wire harness, DC bus to fan power supply – – – 1 1
CBL6 176F3790 Assy, wire, CBL6, P4001, pwr-RFI, E1h Wire harness, power card to HF and RFI 1 1 1 – –
Spare Parts Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 347
