Mains Supply 525-690 V AC
FC 302
P250 P315 P355
High/ Normal Load* HO NO HO NO HO NO
Typical Shaft output at 550 V [kW] 200 250 250 315 315 355
Typical Shaft output at 575 V [hp] 300 350 350 400 400 450
Typical Shaft output at 690 V [kW] 250 315 315 400 355 450
Enclosure IP21 D2 D2 E1
Enclosure IP54 D2 D2 E1
Enclosure IP00 D4 D4 E2
Output current
Continuous
(at 550 V) [A]
303 360 360 418 395 470
Intermittent (60 sec overload)
(at 550 V) [A]
455 396 540 460 593 517
Continuous
(at 575/690 V) [A]
290 344 344 400 380 450
Intermittent (60 s overload)
(at 575/ 690 V) [A]
435 378 516 440 570 495
Continuous KVA
(at 550 V) [KVA]
289 343 343 398 376 448
Continuous KVA
(at 575 V) [KVA]
289 343 343 398 378 448
Continuous KVA
(at 690 V) [KVA]
347 411 411 478 454 538
Max. input current
Continuous
(at 550 V ) [A]
299 355 355 408 381 453
Continuous
(at 575 V) [A]
286 339 339 390 366 434
Continuous
(at 690 V) [A]
296 352 352 400 366 434
Max. cable size, mains, motor and
load share [mm
2
(AWG)]
2 x 150
(2 x 300 mcm)
2 x 150
(2 x 300 mcm)
4 x 240
(4 x 500 mcm)
Max. cable size, brake [mm
2
(AWG)]
2 x 150
(2 x 300 mcm)
2 x 150
(2 x 300 mcm)
2 x 185
(2 x 350 mcm)
Max. external mains fuses [A]
1
500 550 700
Estimated power loss
at 600 V [W]
4)
3552 4307 3971 4756 4130 4974
Estimated power loss
at 690 V [W]
4)
3704 4485 4103 4924 4240 5128
Weight,
enclosure IP21, IP54 [kg]
151 165 263
Weight,
enclosure IP00 [kg]
138 151 221
Efficiency
4)
0.98
Output frequency 0 - 600Hz 0 - 500Hz 0 - 500Hz
Heatsink overtemp. trip
110°C 110°C 110°C
Power card ambient trip
75°C 75°C 75°C
* High overload = 160% torque during 60 s, Normal overload = 110% torque during 60 s.
Table 5.6
General Specifications
VLT
®
Automation Drive FC 300 Operating Instructions
100 MG33U402 - Rev. 2013-12-16
55
