Danfoss VLT AutomationDrive FC 302 User Manual

FC 302
N90K
N110
N132
N160
- Mains with disconnect [mm
2
(AWG)]
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x185 (2x350 mcm)
- Mains with fusible disconnect [mm
2
(AWG)]
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x185 (2x350 mcm)
- Mains with contactor [mm
2
(AWG)]
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x185 (2x350 mcm)
- Motor [mm
2
(AWG)]
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x185 (2x350 mcm)
Drive module power loss at 600 V [W]
(1)(2)(3)
1430
1740
1742
2101
2080
2649
2361
3074
Drive module power loss at 690 V [W]
(1)(2)(3)
1480
1798
1800
2167
2159
2740
2446
3175
Drive efficiency
(2)
0.98
0.98
0.98
0.98
Output frequency [Hz]
(4)
0–590
0–590
0–590
0–590
Heat sink overtemperature trip [°C (°F)]
110 (230)
110 (230)
110 (230)
110 (230)
Control card overtemperature trip [°C (°F)]
75 (167)
75 (167)
75 (167)
75 (167)
PHF overtemperature trip [°C (°F)]
145 (293)
145 (293)
145 (293)
145 (293)
Line reactor overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
150 (302)
dU/dt filter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
150 (302)
Sine-wave filter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
150 (302)
1
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These
values are based on a typical motor efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the drive. Applies to dimension-
ing of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control card power
consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-efficiency-direc-
tive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each
add only 4 W.
2
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Efficiency measured at nominal current. For energy efficien-
cy class, see the Ambient Conditions section. For part load losses, see drives.danfoss.com/knowledge-center/energy-efficiency-directive/#/.
3
See also Input Power Option Losses section.
4
If using an output filter, the output frequency is limited further. See
10.3.1 Motor Output (U, V, W).
Table 106: Electrical Data, Mains Supply 3x525–690 V AC
FC 302
N200
N250
N315
High/normal overload
High overload=150% or 160% torque for a duration of 60 s.
Normal overload=110% torque for a duration of 60 s.
HO
NO
HO
NO
HO
NO
Typical shaft output at 550 V [kW]
160
200
200
250
250
315
Typical shaft output at 575 V [hp]
250
300
300
350
350
400
Typical shaft output at 690 V [kW]
200
250
250
315
315
400
Enclosure size
D10h
D10h
D10h
Output current (3-phase)
Continuous (at 550 V) [A]
253
303
303
360
360
418
Intermittent (60 s overload) (at 550 V) [A]
380
333
455
396
540
460
Continuous (at 575/690 V) [A]
242
290
290
344
344
400
AQ262139143212en-000301 / 130R0879 | 167Danfoss A/S © 2021.10
Specifications
VLT® AutomationDrive FC 302
Operating Guide
