Danfoss VLT AutomationDrive FC 302 User Manual

5.6.3 D10h Wiring Harness
-XDL.1
-XD4.1
-XD11.1
1
2
3
4
e30bu179.11
Illustration 31: Split Shipment Electrical Connections (Input Filter Cabinet + Input Power Options Cabinet + D10h Drive Cabinet)
1
DC-link harness to fan supply in output filter cabinet
2
Cabinet heater supply harness to output filter cabi-
net
3
Additional terminal connections
4
Thermal protection wiring harness to output filter
cabinet
AQ262139143212en-000301 / 130R0879 | 65Danfoss A/S © 2021.10
Electrical Installation
VLT® AutomationDrive FC 302
Operating Guide
