Closed loop wizard
Parameter Option Default Function
0-01 Language
[0] English
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
[28] Bras.port
0 Select the language for the display.
0-06 GridType
[0] 200-240 V/50 Hz/IT-grid
[1] 200-240 V/50 Hz/Delta
[2] 200-240 V/50 Hz
[10] 380-440 V/50 Hz/IT-grid
[11] 380-440 V/50 Hz/Delta
[12] 380-440 V/50 Hz
[20] 440-480 V/50 Hz/IT-grid
[21] 440-480 V/50 Hz/Delta
[22] 440-480 V/50 Hz
[30] 525-600 V/50 Hz/IT-grid
[31] 525-600 V/50 Hz/Delta
[32] 525-600 V/50 Hz
[100] 200-240 V/60 Hz/IT-grid
[101] 200-240 V/60 Hz/Delta
[102] 200-240 V/60 Hz
[110] 380-440 V/60 Hz/IT-grid
[111] 380-440 V/60 Hz/Delta
[112] 380-440 V/60 Hz
[120] 440-480 V/60 Hz/IT-grid
[121] 440-480 V/60 Hz/Delta
[122] 440-480 V/60 Hz
[130] 525-600 V/60 Hz/IT-grid
[131] 525-600 V/60 Hz/Delta
[132] 525-600 V/60 Hz
Size related
Select the operating mode for restart upon
reconnection of the frequency converter to
mains voltage after power down.
0-60 Main Menu Password
0-999 0 Define the password for access to the LCP.
1-00 Configuration Mode
[0] Open loop
[3] Closed loop
[0] Open loop Select closed loop.
1-13 Compressor Selection
[24] VZH028
[25] VZH035
[26] VZH044
Size related Select the used compressor.
3-02 Minimum Reference
-4999.0 - 200 Hz 0 Hz The minimum reference is the lowest value
obtainable by summing all references.
3-03 Maximum Reference
0 - 200 Hz 200 Hz The maximum reference is the highest
obtainable by summing all references
3-10 Preset Reference
-100 - 100 % 0 % Setup a fix set point n preset reference [0].
3-15 Reference 1 Source
[0] No function
[1] Analog in 53
[2] Analog in 54
[7] Pulse input 29
[11] Local bus reference
[1] Analog in 53 Select the input to be used for the reference
signal.
3-41 Ramp 1 Ramp Up Time
0.05-3600.0 s 30.00 s
Ramp up time from 0 to 1-25 Motor Nominal
Speed.
3-42 Ramp 1 Ramp Down Time
0.05-3600.0 s 30.00 s Ramp-down time from rated motor speed to
0.
Quick Guide Quick Guide
18 Danfoss A/S © Rev. 09/2014 All rights reserved. MG18M102
