Danfoss VLT CDS 803 Quick Guide

Parameter Option Default Function
5-12 Terminal 27 Digital Input
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inverse
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[7] External Interlock
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Speed up
[22] Speed down
[23] Set-up select bit 0
[34] Ramp bit 0
[52] Run permissive
[53] Hand start
[54] Auto start
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
[6] Stop inverse
Select the input function for terminal 27.
5-40 Function Relay [0] Function relay
See 5-40 Function Relay Alarm Select the function to control output relay 1.
5-40 Function Relay [1] Function relay
See 5-40 Function Relay Drive running Select the function to control output relay 2.
6-10 Terminal 53 Low Voltage
0-10 V 0.07 V Enter the voltage that corresponds to the low
reference value.
6-11 Terminal 53 High Voltage
0-10 V 10 V Enter the voltage that corresponds to the
high reference value.
6-14 Terminal 53 Low Ref./Feedb.
Value
-4999 - 4999 30 Enter the reference value that corresponds to
the voltage set in 6-10 Terminal 53 Low
Voltage.
6-15 Terminal 53 High Ref./Feedb.
Value
-4999 - 4999 200 Enter the reference value that corresponds to
the voltage set in 6-11 Terminal 53 High
Voltage.
6-22 Terminal 54 Low Current
0.00-20.00 mA 4.00 mA Enter the current that corresponds to the low
reference value.
6-23 Terminal 54 High Current
0-10 V 10 V Enter the current that corresponds to the high
reference value.
6-24 Terminal 54 Low Ref./Feedb.
Value
-0.00-20.00 mA 20.00 mA Enter the reference value that corresponds to
the current set in 6-20 Terminal 54 Low
Voltage.
6-25 Terminal 54 High Ref./Feedb.
Value
-4999 - 4999 Size related Enter the reference value that corresponds to
the current set in 6-21 Terminal 54 High
Voltage.
8-01 Control Site
[0] Digital and ctrl.word
[1] Digital only
[2] Controlword only
0 Select if digital, bus, or a combination of both
should control the frequency converter.
Quick Guide Quick Guide
MG18M102 Danfoss A/S © Rev. 09/2014 All rights reserved. 19
1
1
